23
HCD-M90
3. DVD-DL (dual layer)
Press the [3] key on the remote commander, insert DVD dual layer
disc, and press [ENTER] key on the remote commander, and the
adjustment will be made through the following steps, then adjusted
values will be written to the EEPROM.
DVD Dual Layer Disc Adjustment Steps
1. Sled Tilt Reset
2. Disc Check Memory DL
3. Wait 500 msec
4. Set Disc Type DL
5. LD ON
6. Spdl Start
7. Wait 1 sec, Layer 1 Adjust
8. Focus Servo ON 0
9. Auto Track Offset Adjust
10. Clva ON
11. Wait 500 msec
12. Tracking ON
13. Wait 500 msec
14. Sled ON
15. Check CLV Lock
16. Auto Loop Filter Offset Auto Focus Adjust
17.
18. Auto Focus Gain Adjust
19. Auto Focus Offset Adjust
20. Eq Boost Adjust
21. Auto Loop Filter Offset
22. Auto Track Gain Adjust, Search Check
23. 32Tj Fwd
24. 32Tj Rev
25. 500Tj Fwd
26. 500Tj Rev, Layer 0 Adjust
27. Fj (L1 -> L0)
28. Auto Track Offset Adjust L0
29. Clva ON
30. Wait 500 msec
31. Tracking ON
32. Wait 500 msec
33. Sled ON
34. Check CLV Lock
35. Auto Focus Filter Offset
36. Auto Focus Adjust
37.
38. Auto Focus Gain Adjust
39. Auto Focus Offset Adjust
40. Eq Boost Adjust
41. Auto Loop Filter Offset
42. Auto Track Gain Adjust, Search Check
43. 32Tj Fwd
44. 32Tj Rev
45. 500Tj fwd
46. 500Tj Rev, Layer Jump Check
47. Lj (L0 -> L1)
48. Lj (L1 -> L0)
49. All Servo Stop
Drive Manual Operation
On the Test Mode Menu screen, Press the [2] key on the remote
commander, and the manual operation menu will be displayed. For
the manual operation, each servo on/off control and adjustment can
be executed manually.
## Drive Manual Operation ##
Operation Menu
1. Disc Type
2. Servo Control
3. Track/Layer Jump
4. Manual Adjustment
5. Auto Adjustment
6. Memory Check
7. Sacd Water Mark
0. Disc Check Memory
_
Exit: Return
In using the manual operation menu, take care of the following
points. These commands do not provide protection, thus requiring
correct operation. The sector address or time code field is displayed
when a disc is loaded.
1. Set correctly the disc type to be used on the Disc Type screen.
The disc type must be set after a disc was loaded.
The set disc type is cleared when the tray is opened.
2. After power ON, if the Drive Manual Operation was selected,
first perform “Reset SLED TILT” by opening 1. Disc Type
screen.
3. In case of an alarm, immediately press the DVD x key on the
remote commander to stop the servo operation, and turn the
power OFF.
Basic operation (controllable from front panel or remote
commander)
I/1 Power OFF
DVD x Servo stop
Z DVD
*1
Stop+Eject/Loading
[RETURN]
*2
Return to Operation Menu or Test Mode
Menu
DVD > , DVD .
*2
Transition between sub modes of menu
[1] to [9], [10/0]
*2
Selection of menu items
M , m
*2
Increase/Decrease in manually adjusted
value
*1: Key of front panel
*2: Key of remote commander
