HCD-M90
8282
Approx.
180 mVp-p
Approx.
1.5 Vp-
Approx.
180 mVp-
Approx.
160 mVp-p
Approx.
260 mVp-
Approx.
300 mVp-p
Approx.
550 mVp-
Approx.
600 mVp-p
•Waveforms
– RF-240 Board –
1 IC001 2 (RF IN) (DVD Play Mode)
1 IC001 2 (RF IN) (CD Play Mode)
2 IC001 ra (TE) (DVD Play Mode)
3 IC001 rs (FE) (DVD Play Mode)
2 IC001 ra (TE) (CD Play Mode)
3 IC001 rs (FE) (CD Play Mode)
4 IC001 tl (SIGO) (DVD Play Mode)
–DVD Board –
qa IC302 yd (BCLK), IC503 wg (CDBCKI)
qs IC302 yg (LRCK), IC503 wh (CDLRKI)
qh IC302 <zcn (ADC1) (CD Play Mode)
Approx.
1.4 Vp-
4 IC001 tl (SIGO) (CD Play Mode)
4.2 Vp-
354 ns
Approx.
1.5 Vp-
Approx.
1.4 Vp-
qd IC302 <zx, (RFIN2) (CD Play Mode)
qf IC302 <zcz (RFIN1) (DVD Play Mode)
3.8 Vp-p
22.7 µs
Approx.
160 mVp-
Approx.
260 mVp-p
Approx.
300 mVp-
qg IC302 <zcb (ADC0) (DVD Play Mode)
qh IC302 <zcn (ADC1) (DVD Play Mode)
qg IC302 <zcb (ADC0) (CD Play Mode)
3.5 Vp-p
29.5 ns
qj IC302 <z,x (CLKIN), <z,m (MCKI), <z,. (SCKI)
3.7 Vp-p
29.5 ns
3.8 Vp-
326 ns
3.8 Vp-p
20.8 µs
ql IC503 qk (LRCKO), IC801 5 (LRCKI)
w; IC503 ql (BCKO), IC801 9 (BCKI)
wa IC503 wl (CRPCLKI)
3.8 Vp-p
43.8 ns
40.8 ns
3.9 Vp-p
qk IC503 qs (ACLK) (DVD Play Mode)
qk IC503 qs (ACLK) (CD Play Mode)
300 mVp-
H
800 mVp-
H
800 mVp-
H
ws IC503 uf (YOUT) (Color Bar (NTSC))
ws IC503 uf (YOUT) (Color Bar (PAL))
wd IC503 uj (COUT) (Color Bar (NTSC))
wd IC503 uj (COUT) (Color Bar (PAL))
300 mVp-
