HCD-M90
Pin No. Pin Name I/O Description
58
BYP —
RF AGC gain control terminal
59
SIGO O
Single-ended RF signal output to the ARP
60
VPA —
Power supply terminal (+5V) (RF block and serial port)
61, 62
AIP, AIN I
AGC amp signal input
63, 64
ATON, ATOP O
Differential attenuator signal output
