– 111 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MD LED
R874 1-249-421-11 CARBON 2.2K 5% 1/4W F
R875 1-249-441-11 CARBON 100K 5% 1/4W
R876 1-247-887-00 CARBON 220K 5% 1/4W
R881 1-247-903-00 CARBON 1M 5% 1/4W
< VIBRATOR >
X601 1-760-489-11 VIBRATOR, CERAMIC (5MHz)
X602 1-567-098-41 VIBRATOR, CRYSTAL (32kHz)
**************************************************************
* 1-670-745-21 MD LED BOARD
************
< DIODE >
D905 8-719-057-09 DIODE LNJ801LPDJA (MD INDICATOR)
**************************************************************
* A-4417-317-A PANEL BOARD, COMPLETE
*********************
* 4-993-866-21 HOLDER (FL)
< CAPACITOR >
C901 1-162-306-11 CERAMIC 0.01uF 20% 16V
C902 1-162-306-11 CERAMIC 0.01uF 20% 16V
C903 1-126-160-11 ELECT 1uF 20% 50V
C923 1-164-159-11 CERAMIC 0.1uF 50V
C935 1-124-261-00 ELECT 10uF 20% 50V
C936 1-124-234-00 ELECT 22uF 20% 16V
C937 1-164-159-11 CERAMIC 0.1uF 50V
C940 1-162-282-31 CERAMIC 100PF 10% 50V
C946 1-164-159-11 CERAMIC 0.1uF 50V
C948 1-162-286-31 CERAMIC 220PF 10% 50V
C949 1-162-286-31 CERAMIC 220PF 10% 50V
C950 1-162-286-31 CERAMIC 220PF 10% 50V
C951 1-162-286-31 CERAMIC 220PF 10% 50V
C952 1-162-286-31 CERAMIC 220PF 10% 50V
C953 1-162-286-31 CERAMIC 220PF 10% 50V
C954 1-162-286-31 CERAMIC 220PF 10% 50V
C955 1-162-286-31 CERAMIC 220PF 10% 50V
C956 1-162-286-31 CERAMIC 220PF 10% 50V
C957 1-162-286-31 CERAMIC 220PF 10% 50V
C958 1-162-286-31 CERAMIC 220PF 10% 50V
C959 1-162-286-31 CERAMIC 220PF 10% 50V
C960 1-162-286-31 CERAMIC 220PF 10% 50V
C961 1-162-286-31 CERAMIC 220PF 10% 50V
C962 1-162-286-31 CERAMIC 220PF 10% 50V
C964 1-126-160-11 ELECT 1uF 20% 50V
C965 1-124-589-11 ELECT 47uF 20% 16V
< CONNECTOR >
* CN901 1-568-865-11 SOCKET, CONNECTOR 23P
< DIODE >
D901 8-719-921-48 DIODE MTZJ-5.6C
D902 8-719-057-10 DIODE LNJ301MPUJAB (^ (MD))
D903 8-719-058-17 DIODE LNG401NPYJA (p (MD))
D904 8-719-057-09 DIODE LNJ801LPDJA (r REC)
D906 8-719-057-10 DIODE LNJ301MPUJAB (^ (CD))
D907 8-719-058-17 DIODE LNG401NPYJA (p (CD))
D908 8-719-057-09 DIODE LNJ801LPDJA (CD INDICATOR)
< FLUORESCENT INDICATOR >
FL901 1-517-687-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC901 8-759-297-23 IC M66004M8FP
IC902 8-759-459-83 IC NJL55H400A
< TRANSISTOR >
Q901 8-729-620-05 TRANSISTOR 2SC2603-EF
Q902 8-729-620-05 TRANSISTOR 2SC2603-EF
Q904 8-729-422-57 TRANSISTOR UN4111
Q905 8-729-422-57 TRANSISTOR UN4111
Q906 8-729-422-57 TRANSISTOR UN4111
Q907 8-729-422-57 TRANSISTOR UN4111
Q908 8-729-422-57 TRANSISTOR UN4111
Q909 8-729-422-57 TRANSISTOR UN4111
Q910 8-729-422-57 TRANSISTOR UN4111
< RESISTOR >
R901 1-249-441-11 CARBON 100K 5% 1/4W
R902 1-249-441-11 CARBON 100K 5% 1/4W
R903 1-249-417-11 CARBON 1K 5% 1/4W F
R904 1-249-417-11 CARBON 1K 5% 1/4W F
R907 1-249-441-11 CARBON 100K 5% 1/4W
R908 1-249-435-11 CARBON 33K 5% 1/4W
R909 1-249-417-11 CARBON 1K 5% 1/4W F
R910 1-249-417-11 CARBON 1K 5% 1/4W F
R911 1-249-417-11 CARBON 1K 5% 1/4W F
R912 1-249-417-11 CARBON 1K 5% 1/4W F
R913 1-249-421-11 CARBON 2.2K 5% 1/4W F
R914 1-247-807-31 CARBON 100 5% 1/4W
R915 1-249-409-11 CARBON 220 5% 1/4W F
R916 1-247-807-31 CARBON 100 5% 1/4W
R917 1-247-807-31 CARBON 100 5% 1/4W
R918 1-249-409-11 CARBON 220 5% 1/4W F
R919 1-247-807-31 CARBON 100 5% 1/4W
R920 1-247-807-31 CARBON 100 5% 1/4W
R921 1-247-807-31 CARBON 100 5% 1/4W
R922 1-247-807-31 CARBON 100 5% 1/4W
R924 1-249-407-11 CARBON 150 5% 1/4W F
R925 1-249-407-11 CARBON 150 5% 1/4W F
R928 1-249-411-11 CARBON 330 5% 1/4W
R930 1-247-807-31 CARBON 100 5% 1/4W
R932 1-249-407-11 CARBON 150 5% 1/4W F
R933 1-249-407-11 CARBON 150 5% 1/4W F
R936 1-247-807-31 CARBON 100 5% 1/4W F
R938 1-249-393-11 CARBON 10 5% 1/4W F
R941 1-249-413-11 CARBON 470 5% 1/4W F
R942 1-249-415-11 CARBON 680 5% 1/4W F
R943 1-249-417-11 CARBON 1K 5% 1/4W F
MAIN PANEL
