Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
PANEL
R944 1-249-419-11 CARBON 1.5K 5% 1/4W F
R945 1-249-421-11 CARBON 2.2K 5% 1/4W F
R946 1-249-413-11 CARBON 470 5% 1/4W F
R947 1-249-415-11 CARBON 680 5% 1/4W F
R948 1-249-417-11 CARBON 1K 5% 1/4W F
R949 1-249-419-11 CARBON 1.5K 5% 1/4W F
R950 1-249-421-11 CARBON 2.2K 5% 1/4W F
R951 1-249-425-11 CARBON 4.7K 5% 1/4W F
R952 1-249-430-11 CARBON 12K 5% 1/4W
< SWITCH >
S901 1-473-392-11 ENCODER, ROTARY (VOLUME)
S902 1-762-875-21 SWITCH, KEYBOARD (1/u)
S903 1-762-875-21 SWITCH, KEYBOARD (p (CD))
S904 1-762-875-21 SWITCH, KEYBOARD (^ (CD))
S905 1-762-875-21 SWITCH, KEYBOARD (6 (CD))
S906 1-762-875-21 SWITCH, KEYBOARD (p (MD))
S907 1-762-875-21 SWITCH, KEYBOARD (^ (MD))
S908 1-762-875-21 SWITCH, KEYBOARD (6 (MD))
S909 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S910 1-762-875-21 SWITCH, KEYBOARD
(MD/CD ) +/TUNING +)
S911 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S912 1-762-875-21 SWITCH, KEYBOARD
(MD/CD = 0/TUNING -)
S913 1-762-875-21 SWITCH, KEYBOARD (r REC)
S914 1-762-875-21 SWITCH, KEYBOARD (CD-MD SYNC)
S915 1-762-875-21 SWITCH, KEYBOARD (REPEAT/STEREO/MONO)
S916 1-762-875-21 SWITCH, KEYBOARD
(PLAY MODE/TUNING MODE)
**************************************************************
* A-4417-126-A POWER AMP BOARD, COMPLETE (AEP,UK,EE)
*************************
* A-4417-130-A POWER AMP BOARD, COMPLETE
*************************
(MY,SP,JE,HK,AR,AUS)
* A-4417-134-A POWER AMP BOARD, COMPLETE (US,CND)
*************************
< CAPACITOR >
C1201 1-126-963-11 ELECT 4.7uF 20% 50V
C1202 1-162-288-31 CERAMIC 330PF 10% 50V
C1203 1-162-286-31 CERAMIC 220PF 10% 50V
C1204 1-126-967-11 ELECT 47uF 20% 50V
C1205 1-126-967-11 ELECT 47uF 20% 50V
C1206 1-126-948-11 ELECT 100uF 20% 35V
C1207 1-136-165-00 FILM 0.1uF 5% 50V
C1208 1-126-965-11 ELECT 22uF 20% 50V
C1210 1-136-163-00 FILM 0.068uF 5% 50V
C1211 1-136-163-00 FILM 0.068uF 5% 50V
C1220 1-126-924-11 ELECT 330uF 20% 10V
C1251 1-126-963-11 ELECT 4.7uF 20% 50V
C1252 1-162-288-31 CERAMIC 330PF 10% 50V
C1253 1-162-286-31 CERAMIC 220PF 10% 50V
C1254 1-126-967-11 ELECT 47uF 20% 50V
C1255 1-126-967-11 ELECT 47uF 20% 50V
C1256 1-126-948-11 ELECT 100uF 20% 35V
C1257 1-136-165-00 FILM 0.1uF 5% 50V
C1260 1-136-163-00 FILM 0.068uF 5% 50V
C1261 1-136-163-00 FILM 0.068uF 5% 50V
C1301 1-126-042-11 ELECT 3300uF 20% 35V
C1302 1-126-042-11 ELECT 3300uF 20% 35V
C1303 1-136-165-00 FILM 0.1uF 5% 50V
C1304 1-136-165-00 FILM 0.1uF 5% 50V
< CONNECTOR >
* CN1202 1-565-485-11 CONNECTOR, BOARD TO BOARD 9P
< DIODE >
D1201 8-719-911-19 DIODE 1SS119-25
D1202 8-719-911-19 DIODE 1SS119-25
D1203 8-719-911-19 DIODE 1SS119-25
D1213 8-719-911-19 DIODE 1SS119-25
D1251 8-719-911-19 DIODE 1SS119-25
D1263 8-719-911-19 DIODE 1SS119-25
D1300 8-719-025-03 DIODE RBA-402-SL
< IC >
IC1201 8-749-920-13 IC STK4132MK2
< TRANSISTOR >
Q1201 8-729-620-05 TRANSISTOR 2SC2603-EF
Q1202 8-729-900-80 TRANSISTOR DTC114ES
Q1231 8-729-422-73 TRANSISTOR UN4212
Q1232 8-729-620-05 TRANSISTOR 2SC2603-EF
Q1251 8-729-620-05 TRANSISTOR 2SC2603-EF
< RESISTOR >
R1201 1-249-417-11 CARBON 1K 5% 1/4W F
R1202 1-249-437-11 CARBON 47K 5% 1/4W
R1203 1-249-417-11 CARBON 1K 5% 1/4W F
R1204 1-249-437-11 CARBON 47K 5% 1/4W
R1205 1-260-103-11 CARBON 2.2K 5% 1/2W
R1207 1-260-103-11 CARBON 2.2K 5% 1/2W
! R1209 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R1210 1-217-151-00 METAL 0.22 10% 2W
R1211 1-249-417-11 CARBON 1K 5% 1/4W F
R1212 1-249-431-11 CARBON 15K 5% 1/4W
R1214 1-260-099-11 CARBON 1K 5% 1/2W
R1217 1-260-099-11 CARBON 1K 5% 1/2W
R1218 1-249-397-11 CARBON 22 5% 1/4W F
R1219 1-249-397-11 CARBON 22 5% 1/4W F
R1225 1-249-397-11 CARBON 22 5% 1/4W F
R1226 1-249-429-11 CARBON 10K 5% 1/4W
R1227 1-247-854-11 CARBON 9.1K 5% 1/4W
(AEP,UK,EE,MY,SP,JE,HK,AR,AUS)
R1227 1-249-429-11 CARBON 10K 5% 1/4W
(US,CND)
R1228 1-247-880-11 CARBON 110K 5% 1/4W
(AEP,UK,EE)
R1228 1-249-441-11 CARBON 100K 5% 1/4W
(US,CND,MY,SP,JE,HK,AR,AUS)
POWER AMP
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
To Next Page
