– 113 –
ST TERMINAL TRANSSW
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R1229 1-249-429-11 CARBON 10K 5% 1/4W
R1231 1-247-807-31 CARBON 100 5% 1/4W
R1232 1-249-429-11 CARBON 10K 5% 1/4W
R1233 1-249-429-11 CARBON 10K 5% 1/4W
! R1243 1-217-637-00 FUSIBLE 1 5% 1/4W F
R1251 1-249-417-11 CARBON 1K 5% 1/4W F
R1252 1-249-437-11 CARBON 47K 5% 1/4W
R1253 1-249-417-11 CARBON 1K 5% 1/4W F
R1254 1-249-437-11 CARBON 47K 5% 1/4W
R1255 1-260-103-11 CARBON 2.2K 5% 1/2W
R1257 1-260-103-11 CARBON 2.2K 5% 1/2W
! R1259 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R1260 1-217-151-00 METAL 0.22 10% 2W
R1261 1-249-417-11 CARBON 1K 5% 1/4W F
R1262 1-249-431-11 CARBON 15K 5% 1/4W
R1268 1-249-397-11 CARBON 22 5% 1/4W F
R1269 1-249-397-11 CARBON 22 5% 1/4W F
R1271 1-249-431-11 CARBON 15K 5% 1/4W
R1272 1-249-431-11 CARBON 15K 5% 1/4W
R1273 1-249-413-11 CARBON 470 5% 1/4W F
< THERMISTOR(POSITIVE) >
THP1230 1-807-796-11 THERMISTOR
**************************************************************
* 1-666-905-11 ST TERMINAL BOARD
*****************
< CONNECTOR >
CN744 1-568-834-11 SOCKET, CONNECTOR 15P
CN745 1-774-289-11 PIN, CONNECTOR (PC BOARD) 15P
**************************************************************
* 1-667-719-11 SW BOARD
********
< CONNECTOR >
CN601 1-770-697-11 CONNECTOR, FFC/FPC 14P
CN602 1-778-638-21 PIN, CONNECTOR (PC BOARD) 2P
CN603 1-778-638-21 PIN, CONNECTOR (PC BOARD) 2P
< SWITCH >
S681 1-572-467-61 SWITCH, PUSH (1 KEY)(LIMIT IN)
S682 1-692-377-31 SWITCH, PUSH (1 KEY)(REFLECT)
S683 1-692-847-21 SWITCH, PUSH (1 KEY)(PROTECT)
S685 1-572-467-61 SWITCH, PUSH (1 KEY)(CHUCKING IN)
S686 1-762-621-21 SWITCH, PUSH (1 KEY)(PACK OUT)
S687 1-572-688-11 SWITCH, PUSH (1 KEY)(PB POSITION)
S688 1-762-621-21 SWITCH, PUSH (1 KEY)(REC POSITION)
**************************************************************
* 1-666-904-11 TRANS BOARD
***********
< CONNECTOR >
CN1600 1-564-321-00 PIN, CONNECTOR 2P
* CN1601 1-564-518-11 PLUG, CONNECTOR 3P
CN1602 1-564-523-11 PLUG, CONNECTOR 8P
< FUSE >
! F1601 1-532-388-31 FUSE (T2AL/250V)(MY,SP,JE,HK,AR,AUS)
! F1603 1-532-504-31 FUSE (T4AL/250V)
(AEP,UK,EE,MY,SP,JE,HK,AR,AUS)
! F1603 1-533-419-11 FUSE, GLASS CYLINDRICAL (DIA.5)(4A/125V)
(US,CND)
! F1605 1-532-504-31 FUSE (T4AL/250V)
(AEP,UK,EE,MY,SP,JE,HK,AR,AUS)
! F1605 1-533-419-11 FUSE, GLASS CYLINDRICAL (DIA.5)(4A/125V)
(US,CND)
< FUSE HOLDER >
FH1601 1-533-293-11 FUSE HOLDER (MY,SP,JE,HK,AR,AUS)
FH1602 1-533-293-11 FUSE HOLDER (MY,SP,JE,HK,AR,AUS)
FH1603 1-533-293-11 FUSE HOLDER
FH1604 1-533-293-11 FUSE HOLDER
FH1605 1-533-293-11 FUSE HOLDER
FH1606 1-533-293-11 FUSE HOLDER
< RESISTOR >
! R1600 1-202-725-00 SOLID 3.3M 10% 1/2W
(US,CND)
< SWITCH >
! S1600 1-762-753-11 SWITCH, VOLTAGE SELECTION
(MY,SP,JE,HK,AR,AUS)
< TRANSFORMER >
! T1600 1-431-498-11 TRANSFORMER, POWER (MY,SP,JE,HK,AR,AUS)
! T1600 1-431-988-11 TRANSFORMER, POWER (AEP,UK,EE)
! T1600 1-431-989-11 TRANSFORMER, POWER (US,CND)
< THERMISTOR(POSITIVE) >
THP1600 1-801-696-11 THERMISTOR, POSITIVE
THP1601 1-801-696-11 THERMISTOR, POSITIVE
THP1602 1-801-671-11 THERMISTOR, POSITIVE
THP1603 1-801-671-11 THERMISTOR, POSITIVE
**************************************************************
MISCELLANEOUS
*************
10 1-782-793-11 WIRE (FLAT TYPE) (23 CORE)
52 1-782-990-11 WIRE (FLAT TYPE) (19 CORE)
56 1-782-991-11 WIRE (FLAT TYPE) (15 CORE)
62 1-233-544-21 ENCAPSULATED COMPONENT (US,CND)
62 1-233-546-21 ENCAPSULATED COMPONENT
(MY,SP,JE,HK,AR,AUS)
62 1-693-387-21 TUNER (FM/MW/LW)(AEP,UK,EE)
64 1-783-213-11 WIRE (FLAT TYPE) (15 CORE)
! 68 1-569-008-21 ADAPTOR, CONVERSION 2P (MY,SP,JE)
! 69 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK,EE,HK)
102 1-660-966-11 OP RELAY FLEXIBLE BOARD
103 1-782-683-11 WIRE (FLAT TYPE) (14 CORE)
110 1-783-113-11 WIRE (FLAT TYPE) (25 CORE)
POWER AMP
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
To Next Page
