Sony HCD-XG500 - Bookshelf System - MAIN Board, Fan, D.C. (M901) (Except AEP, UK Models); MAIN Board (AEP, UK Models)

10
HCD-XG60/XG500
3-5. MAIN BOARD, FAN, D.C. (M901) (EXCEPT AEP, UK MODELS)
3-6. MAIN BOARD (AEP, UK MODELS)
9 wire (flat type) (19 core)
(CN411)
7 fan, D.C.
(M901)
8 back panel
1 wire (flat type)
(13 core) (CN441)
3 eight screws
(BVTP3
× 8)
3 three screws
(BVTP3
× 8)
3 three screws
(BVTP3
× 8)
6 two screws
(BVTP3
× 8)
3 screw
(BVTP3
× 8)
2 jumper plug
US, Canadian, Mexican models
3 three screws
(BVTP3
× 8)
qa two screws
(BVTP3
× 8)
qs two connectors
(CN803, 804)
0 connector
(CN412)
4
5
connector (CN903)
qd MAIN board
6 wire (flat type) (19 core)
(CN411)
5 back panel
1 wire (flat type)
(15 core) (CN441)
3 seven screws
(BVTP3
× 8)
3 three screws
(BVTP3
× 8)
3 three screws
(BVTP3
× 8)
3 screw
(BVTP3
× 8
)
2 jumper plug
3 three screws
(BVTP3
× 8)
8 two screws
(BVTP3
× 8)
9 two connectors
(CN803, 804)
7 connector
(CN412)
4
0
MAIN board
