HCD-XG60/XG500
4242
7-24. PRINTED WIRING BOARDS – PANEL VR/ILLUMINATION Boards – • See page 23 for Circuit Boards Location.
• Semiconductor
Location
Ref. No. Location
There are a few cases that the part isn't mounted in model
is printed on diagrams.
D701 C-10
D702 C-10
D703 C-9
D704 C-9
D705 C-8
D706 C-8
D707 C-7
D708 C-7
D709 C-6
D710 C-6
D713 D-7
D714 D-4
D715 D-10
D716 D-9
D717 B-13
D718 C-13
D719 C-12
D791 A-11
IC701 D-10
IC702 A-11
ILLUMINATION
BOARD
1-680-167-
(11)
11
D791
(ILLUMINATION)
(CHASSIS)
4
3
1
2
PANEL VR BOARD
S736
ROTARY ENCODER
VOLUME
13
ENTER
D714, S708
P. FILE FLAT
PTY
STEREO/MONO
+
–
(AEP, UK)
TUNING
MODE
S707
S706
TUNER/BAND
D713, S704
B
V
v
b
SALSA
D710, S721
DANCE
D708, S719
JAZZ
D706, S717
GAME
D709, S722
SAMBA
D705, S718
TANGO
D707, S720
REGGAE
D703, S729
GUITAR
D704, S716
ROCK
D702, S727
ENTER/NEXT
D716, S702
TUNER/MEMORY
GUITAR DISTORTION
S701
D715, S731
MOVE
D701, S729
MIC GUITAR/
KARAOKE
U
PANEL FL
BOARD
CN602
GROOVE
D717, S713
SUPER WOOFER
D718, S714
SUPER WOOFER MODE
S715
1-680-170-
(11)
11
SURROUND
D719, S712
S701 – 710,
S712 – S732
(CHASSIS)
1
1
4
3
A
B
C
D
1 2 3 4 5 6 7 8 9 10 11 12 13
(Page 40)
