8
HCD-XG60/XG500
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
SECTION 3
DISASSEMBLY
Note: Follow the disassembly procedure in the numerical order given.
3-2. CASE
3-2. CASE
(Page 8)
3-3. FRONT PANEL SECTION
(Page 9)
3-4. COVER (TC),
TAPE MECHANISM DECK
(TCM-230PWR42)
(Page 9)
3-7. CD MECHANISM DECK
(CDM37M-5BD32L)
(Page 11)
3-8. BASE UNIT
(BU-5BD32L)
(Page 12)
3-9. DISC TABLE
(Page 12)
3-6. MAIN BOARD
(AEP, UK MODELS)
(Page 10)
3-5. MAIN BOARD,
FAN, D.C. (M901)
(EXCEPT AEP, UK MODELS)
(Page 10)
SET
1
three screws
(CASE3 TP2)
1
three screws
(CASE3 TP2)
2
five screws
(BVTT3
×
6)
3
two screws
(BVTP3
×
8
)
4
4
5
5
6
case
