9
HCD-XG60/XG500
3-3. FRONT PANEL SECTION
3-4. COVER (TC), TAPE MECHANISM DECK (TCM-230PWR42)
1
wire (flat type)
(15 core) (CN303)
2
two connectors
(CN452, 702)
1
wire (flat type)
(17 core) (CN304)
1
wire (flat type)
(13 core) (CN431)
3
screw
(BVTP3
×
8
)
4
two lugs
4
lug
2
connector
(CN806)
5
screw
(BVTP3
×
8)
6
claw
5
four screws
(BVTP3
×
8)
7
front panel section
3
two screws
(BVTP3
×
8)
1
five claws
2
cover (TC)
4
two screws
(BVTP3
×
8)
3
wire (flat type) (17 core)
(CN1001)
3
wire (flat type) (15 core
)
(CN601)
4
two screws
(BVTP3
×
8)
5
tape mechanism deck
(TCM-230PWR42)
