Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
65
HCD-XG60/XG500
BD CD MOTOR CD-L CD-R (1)
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
R171 1-216-078-00 RES-CHIP 16K 5% 1/10W
R172 1-216-073-00 METAL CHIP 10K 5% 1/10W
R173 1-216-077-00 RES-CHIP 15K 5% 1/10W
R181 1-216-078-00 RES-CHIP 16K 5% 1/10W
R182 1-216-073-00 METAL CHIP 10K 5% 1/10W
R183 1-216-077-00 RES-CHIP 15K 5% 1/10W
< NETWORK RESITOR >
RN101 1-233-576-11 RES, CHIP NETWORK 100
RN102 1-233-576-11 RES, CHIP NETWORK 100
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
< VIBRATOR >
X101 1-767-408-21 VIBRATOR, CRYSTAL (16.9344MHz)
**************************************************************
* A-4673-765-A CD MOTOR BOARD, COMPLETE
*************************
* 4-980-385-01 HOLDER (SW)
< CAPACITOR >
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-164-159-21 CERAMIC 0.1uF 50V
C203 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN201 1-568-947-11 PIN, CONNECTOR 9P
< IC >
IC201 8-759-365-94 IC TA8409S
< COIL >
L201 1-408-117-00 INDUCTOR 10uH
< RESISTOR >
R205 1-249-427-11 CARBON 6.8K 5% 1/4W
R206 1-249-425-11 CARBON 4.7K 5% 1/4W
< SWITCH >
S201 1-762-587-11 SWITCH, PUSH (1 KEY) (UP)
**************************************************************
CD-L BOARD
***********
< CAPACITOR >
C741 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN704 1-785-332-11 PIN, CONNECTOR (LIGHT ANGLE) 6P
< LED >
D741 8-719-058-04 LED SEL5223S-TP15 (NON-STOP)
< RESISTOR >
R741 1-249-407-11 CARBON 150 5% 1/4W
R742 1-249-438-11 CARBON 56K 5% 1/4W
R743 1-249-420-11 CARBON 1.8K 5% 1/4W
R744 1-249-422-11 CARBON 2.7K 5% 1/4W
R745 1-247-843-11 CARBON 3.3K 5% 1/4W
R746 1-249-425-11 CARBON 4.7K 5% 1/4W
R747 1-249-427-11 CARBON 6.8K 5% 1/4W
R748 1-249-429-11 CARBON 10K 5% 1/4W
R749 1-249-431-11 CARBON 15K 5% 1/4W
R750 1-249-434-11 CARBON 27K 5% 1/4W
< SWITCH >
S741 1-762-875-21 SWITCH, KEYBOARD (LOOP)
S742 1-762-587-11 SWITCH, PUSH (1 KEY)
(LID (CD) OPEN/CLOSE)
S743 1-762-875-21 SWITCH, KEYBOARD (FLASH)
S744 1-762-875-21 SWITCH, KEYBOARD (EDIT)
S745 1-762-875-21 SWITCH, KEYBOARD (NON-STOP)
S746 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S747 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S748 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S749 1-762-875-21 SWITCH, KEYBOARD (DISC 4)
S750 1-762-875-21 SWITCH, KEYBOARD (DISC 5)
**************************************************************
CD-R (1) BOARD
**************
< CONNECTOR >
CN703 1-785-333-11 PIN, CONNECTOR (LIGHT ANGLE) 7P
< LED >
D700 8-719-056-13 LED SML79423C-TP15 (HX)
< RESISTOR >
R751 1-249-415-11 CARBON 680 5% 1/4W
R752 1-249-417-11 CARBON 1K 5% 1/4W
R753 1-249-418-11 CARBON 1.2K 5% 1/4W
R754 1-249-420-11 CARBON 1.8K 5% 1/4W
R755 1-249-422-11 CARBON 2.7K 5% 1/4W
R756 1-247-843-11 CARBON 3.3K 5% 1/4W
R757 1-249-425-11 CARBON 4.7K 5% 1/4W
R758 1-249-403-11 CARBON 68 5% 1/4W
R759 1-249-403-11 CARBON 68 5% 1/4W
< SWITCH >
S751 1-762-875-21 SWITCH, KEYBOARD (HX)
S752 1-762-875-21 SWITCH, KEYBOARD (x)
S753 1-762-875-21 SWITCH, KEYBOARD (m)
S754 1-762-875-21 SWITCH, KEYBOARD (M)
S755 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP)
S756 1-762-875-21 SWITCH, KEYBOARD (REPEAT)
S757 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE)
**************************************************************
