Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
66
HCD-XG60/XG500
CD-R (2) BOARD
**************
< CAPACITOR >
C751 1-162-306-11 CERAMIC 0.01uF 30% 16V
C752 1-162-306-11 CERAMIC 0.01uF 30% 16V
< ROTARY ENCODER >
S763 1-473-393-11 ENCODER, ROTARY (JOG DIAL)
**************************************************************
FRONT INPUT BOARD
******************
< CAPACITOR >
C801 1-162-294-31 CERAMIC 0.001uF 10% 50V
C802 1-162-294-31 CERAMIC 0.001uF 10% 50V
C803 1-126-960-11 ELECT 1uF 20% 50V
C811 1-162-282-31 CERAMIC 100PF 10% 50V
C812 1-164-159-21 CERAMIC 0.1uF 50V
< NOISE FILTER >
FL803 1-424-228-11 FILTER, NOISE
< JACK >
J804 1-815-310-11 JACK 3P (GAME INPUT AUDIO/VIDEO)
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-417-11 CARBON 1K 5% 1/4W
R804 1-249-437-11 CARBON 47K 5% 1/4W
R805 1-247-804-11 CARBON 75 5% 1/4W
**************************************************************
HEADPHONES BOARD
******************
< CAPACITOR >
C891 1-162-294-31 CERAMIC 0.001uF 10% 50V
C892 1-162-294-31 CERAMIC 0.001uF 10% 50V
C893 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN802 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE) 4P
< JACK >
J803 1-770-226-11 JACK (LARGE TYPE) (PHONES)
< RESISTOR >
R810 1-247-807-31 CARBON 100 5% 1/4W
**************************************************************
CD-R (2) FRONT INPUT HEADPHONES ILLUMINATION LEAF SW
ILLUMINATION BOARD
*******************
< CAPACITOR >
C791 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C792 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C793 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CN791 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
< LED >
D791 8-719-075-87 LED SECU3M02C (ILLUMINATION)
**************************************************************
A-2007-852-A LEAF SW BOARD, COMPLETE
************************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-784-459-11 CONNECTOR, FFC/FPC 17P
< DIODE >
D1001 8-719-991-33 DIODE 1SS133T-77
D1002 8-719-991-33 DIODE 1SS133T-77
< PHOTO INTERRUPTER >
IC1001 8-749-014-38 PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA
< RESISTOR >
R907 1-249-441-11 CARBON 100K 5% 1/4W
R1001 1-249-409-11 CARBON 220 5% 1/4W
R1002 1-249-409-11 CARBON 220 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-91 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-852-11 CARBON 7.5K 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY) (DECK A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY) (DECK B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (DECK A HALF)
S1004 1-771-205-11 SWITCH, LEAF (DECK A 120/70)
S1005 1-771-205-11 SWITCH, LEAF (DECK A REC)
