Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
73
HCD-XG60/XG500
C832 1-126-967-11 ELECT 47uF 20% 50V
C841 1-127-751-11 ELECT 3300uF 20% 50V
(EA, SP)
C841 1-127-753-11 ELECT 3300uF 20% 71V
(XG500)
C841 1-127-811-11 ELECT 3300uF 20% 50V
(E2, MX, AR)
C842 1-127-755-11 ELECT 3300uF 20% 100V
(EA, SP)
C842 1-127-815-11 ELECT 3300uF 20% 100V
(E2, MX, AR)
C844 1-130-777-00 MYLAR 0.1uF 10% 100V
(XG60)
C845 1-126-943-11 ELECT 2200uF 20% 25V
C847 1-164-159-21 CERAMIC 0.1uF 50V
C848 1-164-159-21 CERAMIC 0.1uF 50V
C849 1-164-159-21 CERAMIC 0.1uF 50V
C850 1-107-721-11 ELECT 4.7uF 20% 100V
C851 1-128-582-11 ELECT 10uF 20% 100V
C852 1-162-290-31 CERAMIC 470PF 10% 50V
C853 1-162-286-21 CERAMIC 220PF 10% 50V
C854 1-126-967-11 ELECT 47uF 20% 50V
C857 1-128-560-11 ELECT 22uF 20% 100V
C858 1-164-159-11 CERAMIC 0.1uF 20% 50V
C859 1-164-159-11 CERAMIC 0.1uF 20% 50V
C861 1-130-491-00 MYLAR 0.047uF 5% 50V
C862 1-130-491-00 MYLAR 0.047uF 5% 50V
C863 1-126-961-11 ELECT 2.2uF 20% 50V
C891 1-127-751-11 ELECT 3300uF 20% 50V
(EA, SP)
C891 1-127-753-11 ELECT 3300uF 20% 71V
(XG500)
C891 1-127-811-11 ELECT 3300uF 20% 50V
(E2, MX, AR)
C892 1-127-755-11 ELECT 3300uF 20% 100V
(EA, SP)
C892 1-127-815-11 ELECT 3300uF 20% 100V
(E2, MX, AR)
C894 1-130-777-00 MYLAR 0.1uF 10% 100V
(XG60)
C895 1-107-721-11 ELECT 4.7uF 20% 100V
C902 1-164-159-21 CERAMIC 0.1uF 50V
C903 1-126-933-11 ELECT 100uF 20% 16V
C904 1-126-964-11 ELECT 10uF 20% 50V
C905 1-126-968-11 ELECT 100uF 20% 50V
C906 1-126-943-11 ELECT 2200uF 20% 25V
C909 1-164-159-21 CERAMIC 0.1uF 50V
C910 1-104-664-11 ELECT 47uF 20% 16V
< CONNECTOR >
CN803 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN804 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN901 1-564-321-00 PIN, CONNECTOR 2P
CN904 1-785-316-11 PIN, CONNECTOR (STRAIGHT) 4P
< DIODE >
D401 8-719-991-33 DIODE 1SS133T-77
D402 8-719-991-33 DIODE 1SS133T-77
D405 8-719-991-33 DIODE 1SS133T-77
D406 8-719-991-33 DIODE 1SS133T-77
D801 8-719-991-33 DIODE 1SS133T-77
D802 8-719-110-39 DIODE RD15ESB1 (XG60)
D803 8-719-991-33 DIODE 1SS133T-77
D804 8-719-991-33 DIODE 1SS133T-77
D805 8-719-991-33 DIODE 1SS133T-77
D831 8-719-510-68 DIODE D5SBA204101 (XG60)
D833 8-719-200-82 DIODE 11ES2
D834 8-719-200-82 DIODE 11ES2
D835 8-719-200-82 DIODE 11ES2
D836 8-719-200-82 DIODE 11ES2
D841 8-719-200-82 DIODE 11ES2
D842 8-719-200-82 DIODE 11ES2
D843 8-719-200-82 DIODE 11ES2
D844 8-719-200-82 DIODE 11ES2
D851 8-719-991-33 DIODE 1SS133T-77
D852 8-719-110-39 DIODE RD15ESB1 (XG60)
D853 8-719-991-33 DIODE 1SS133T-77
D902 8-719-210-21 DIODE 11EQS04
D903 8-719-210-21 DIODE 11EQS04
D904 8-719-210-21 DIODE 11EQS04
D905 8-719-210-21 DIODE 11EQS04
D906 8-719-991-33 DIODE 1SS133T-77
D911 8-719-982-24 DIODE MTZJ-33A
D912 8-719-109-89 DIODE RD5.6ESB2
< IC >
IC801 8-749-017-05 IC STK412-040 (XG60)
IC801 8-749-017-16 IC STK442-130 (XG500)
IC901 8-759-450-47 IC BA05T
< COIL >
L401 1-420-872-00 COIL, AIR-CORE (AEP, UK)
L402 1-420-872-00 COIL, AIR-CORE (AEP, UK)
< TRANSISTOR >
Q401 8-729-029-40 TRANSISTOR DTA124ESA (XG60)
Q401 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA (XG500)
Q402 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q431 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q432 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q433 8-729-620-05 TRANSISTOR 2SC2603-EF
Q434 8-729-620-05 TRANSISTOR 2SC2603-EF
Q437 8-729-620-05 TRANSISTOR 2SC2603-EF
Q439 8-729-620-05 TRANSISTOR 2SC2603-EF
Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q803 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q804 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q805 8-729-231-55 TRANSISTOR 2SC2878-AB
Q831 8-729-029-86 TRANSISTOR DTC124ESA
Q832 8-729-620-05 TRANSISTOR 2SC2603-EF
Q833 8-729-029-40 TRANSISTOR DTA124ESA
Q834 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q855 8-729-231-55 TRANSISTOR 2SC2878-AB
Q901 8-729-620-05 TRANSISTOR 2SC2603-EF
Q903 8-729-048-52 TRANSISTOR 2SA1932 (TP)
Q908 8-729-119-76 TRANSISTOR 2SA1175-HFE
