Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
74
HCD-XG60/XG500
< RESISTOR >
0 R401 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
(AEP, UK)
0 R401 1-216-431-11 METAL OXIDE 560 5% 1W F
(E)
0 R401 1-216-458-11 METAL OXIDE 1.8K 5% 2W F
(US, CND)
R406 1-249-437-11 CARBON 47K 5% 1/4W
R407 1-249-437-11 CARBON 47K 5% 1/4W
R410 1-249-389-11 CARBON 4.7 5% 1/4W
(AEP, UK)
R411 1-249-389-11 CARBON 4.7 5% 1/4W
(AEP, UK)
R412 1-249-389-11 CARBON 4.7 5% 1/4W
(AEP, UK)
R413 1-249-389-11 CARBON 4.7 5% 1/4W
(AEP, UK)
R414 1-260-076-11 CARBON 10 5% 1/2W
(AEP, UK)
R415 1-260-076-11 CARBON 10 5% 1/2W
(AEP, UK)
R429 1-249-437-11 CARBON 47K 5% 1/4W
R431 1-249-438-11 CARBON 56K 5% 1/4W
R432 1-249-437-11 CARBON 47K 5% 1/4W
R434 1-249-433-11 CARBON 22K 5% 1/4W
R437 1-249-429-11 CARBON 10K 5% 1/4W
R439 1-249-425-11 CARBON 4.7K 5% 1/4W
R440 1-249-433-11 CARBON 22K 5% 1/4W
(XG60)
R440 1-249-437-11 CARBON 47K 5% 1/4W
(XG500)
R441 1-249-435-11 CARBON 33K 5% 1/4W
R446 1-249-429-11 CARBON 10K 5% 1/4W
R447 1-249-437-11 CARBON 47K 5% 1/4W
R460 1-249-429-11 CARBON 10K 5% 1/4W
(XG500)
R801 1-249-417-11 CARBON 1K 5% 1/4W
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-415-11 CARBON 680 5% 1/4W
R804 1-249-435-11 CARBON 33K 5% 1/4W
0 R805 1-216-436-00 METAL OXIDE 3.9K 5% 1W F
(XG60)
0 R806 1-216-436-00 METAL OXIDE 3.9K 5% 1W F
(XG60)
0 R807 1-212-881-11 FUSIBLE 100 5% 1/4W F
0 R808 1-220-893-11 METAL 0.22 10% 5W F
R809 1-260-076-11 CARBON 10 5% 1/2W
R810 1-249-437-11 CARBON 47K 5% 1/4W
R811 1-249-417-11 CARBON 1K 5% 1/4W
R812 1-249-431-11 CARBON 15K 5% 1/4W
R813 1-249-441-11 CARBON 100K 5% 1/4W
R814 1-249-421-11 CARBON 2.2K 5% 1/4W
R815 1-249-433-11 CARBON 22K 5% 1/4W
R816 1-249-429-11 CARBON 10K 5% 1/4W
R817 1-249-421-11 CARBON 2.2K 5% 1/4W
R818 1-249-409-11 CARBON 220 5% 1/4W
R819 1-249-439-11 CARBON 68K 5% 1/4W
0 R820 1-202-972-61 FUSIBLE 1 5% 1/4W F
R821 1-249-435-11 CARBON 33K 5% 1/4W
R822 1-249-433-11 CARBON 22K 5% 1/4W
R823 1-249-433-11 CARBON 22K 5% 1/4W
R824 1-249-413-11 CARBON 470 5% 1/4W
0 R825 1-215-891-11 METAL OXIDE 680 5% 2W F
R827 1-249-441-11 CARBON 100K 5% 1/4W
R828 1-247-903-00 CARBON 1M 5% 1/4W
R831 1-249-441-11 CARBON 100K 5% 1/4W
R832 1-249-441-11 CARBON 100K 5% 1/4W
R833 1-249-432-11 CARBON 18K 5% 1/4W
(XG60)
R833 1-249-433-11 CARBON 22K 5% 1/4W
(XG500)
R834 1-249-429-11 CARBON 10K 5% 1/4W
R835 1-249-437-11 CARBON 47K 5% 1/4W
R836 1-249-417-11 CARBON 1K 5% 1/4W
R837 1-249-435-11 CARBON 33K 5% 1/4W
R838 1-249-435-11 CARBON 33K 5% 1/4W
R839 1-249-441-11 CARBON 100K 5% 1/4W
(XG60)
R840 1-249-402-11 CARBON 56 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W
R852 1-249-437-11 CARBON 47K 5% 1/4W
R853 1-249-415-11 CARBON 680 5% 1/4W
0 R855 1-215-891-11 METAL OXIDE 680 5% 2W F
0 R857 1-212-881-11 FUSIBLE 100 5% 1/4W F
0 R858 1-220-893-11 METAL 0.22 10% 5W F
R859 1-260-076-11 CARBON 10 5% 1/2W
R860 1-249-437-11 CARBON 47K 5% 1/4W
R861 1-249-417-11 CARBON 1K 5% 1/4W
R862 1-249-431-11 CARBON 15K 5% 1/4W
R863 1-249-441-11 CARBON 100K 5% 1/4W
R864 1-249-425-11 CARBON 4.7K 5% 1/4W
R865 1-249-433-11 CARBON 22K 5% 1/4W
R868 1-249-409-11 CARBON 220 5% 1/4W
R880 1-249-402-11 CARBON 56 5% 1/4W
0 R888 1-220-893-11 METAL 0.22 10% 5W F
R889 1-249-441-11 CARBON 100K 5% 1/4W
(XG60)
0 R898 1-220-893-11 METAL 0.22 10% 5W F
R901 1-249-429-11 CARBON 10K 5% 1/4W
R902 1-249-441-11 CARBON 100K 5% 1/4W
R903 1-249-429-11 CARBON 10K 5% 1/4W
R904 1-249-417-11 CARBON 1K 5% 1/4W
R905 1-249-429-11 CARBON 10K 5% 1/4W
R906 1-247-807-31 CARBON 100 5% 1/4W
R907 1-247-807-31 CARBON 100 5% 1/4W
R915 1-247-791-91 CARBON 22 5% 1/4W
0 R916 1-215-916-00 METAL OXIDE 680 5% 3W F
(XG60)
< RELAY >
RY401 1-515-920-11 RELAY
< THERMISTOR >
TH831 1-807-796-11 THERMISTOR
PA
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
