Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
77
HCD-XG60/XG500
R721 1-249-420-11 CARBON 1.8K 5% 1/4W
R722 1-249-422-11 CARBON 2.7K 5% 1/4W
R723 1-247-843-11 CARBON 3.3K 5% 1/4W
R724 1-249-425-11 CARBON 4.7K 5% 1/4W
R725 1-249-420-11 CARBON 1.8K 5% 1/4W
R726 1-249-422-11 CARBON 2.7K 5% 1/4W
R727 1-247-843-11 CARBON 3.3K 5% 1/4W
R728 1-249-425-11 CARBON 4.7K 5% 1/4W
R729 1-249-427-11 CARBON 6.8K 5% 1/4W
R730 1-249-429-11 CARBON 10K 5% 1/4W
(AEP, UK)
R734 1-249-417-11 CARBON 1K 5% 1/4W
R735 1-249-417-11 CARBON 1K 5% 1/4W
R736 1-249-401-11 CARBON 47 5% 1/4W
R737 1-247-807-31 CARBON 100 5% 1/4W
R738 1-247-807-31 CARBON 100 5% 1/4W
R739 1-247-807-31 CARBON 100 5% 1/4W
R740 1-249-429-11 CARBON 10K 5% 1/4W
R771 1-249-403-11 CARBON 68 5% 1/4W
R772 1-249-403-11 CARBON 68 5% 1/4W
R773 1-249-403-11 CARBON 68 5% 1/4W
R774 1-249-403-11 CARBON 68 5% 1/4W
R775 1-249-403-11 CARBON 68 5% 1/4W
R776 1-249-403-11 CARBON 68 5% 1/4W
R777 1-249-403-11 CARBON 68 5% 1/4W
R778 1-249-403-11 CARBON 68 5% 1/4W
R779 1-249-403-11 CARBON 68 5% 1/4W
R780 1-249-403-11 CARBON 68 5% 1/4W
R783 1-249-403-11 CARBON 68 5% 1/4W
R784 1-249-407-11 CARBON 150 5% 1/4W
R785 1-249-407-11 CARBON 150 5% 1/4W
R786 1-249-407-11 CARBON 150 5% 1/4W
R787 1-249-407-11 CARBON 150 5% 1/4W
R788 1-249-407-11 CARBON 150 5% 1/4W
R789 1-249-403-11 CARBON 68 5% 1/4W
R790 1-249-409-11 CARBON 220 5% 1/4W
R791 1-249-409-11 CARBON 220 5% 1/4W
R792 1-249-406-11 CARBON 120 5% 1/4W
< SWITCH >
S701 1-762-875-21 SWITCH, KEYBOARD (TUNER MEMORY)
S702 1-762-875-21 SWITCH, KEYBOARD (ENTER/NEXT)
S703 1-762-875-21 SWITCH, KEYBOARD (–)
S704 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S705 1-762-875-21 SWITCH, KEYBOARD (+)
S706 1-762-875-21 SWITCH, KEYBOARD (STEREO/MONO)
S707 1-762-875-21 SWITCH, KEYBOARD (TUNING MODE)
S708 1-762-875-21 SWITCH, KEYBOARD (ENTER)
S709 1-762-875-21 SWITCH, KEYBOARD (P.FILE)
S710 1-762-875-21 SWITCH, KEYBOARD (FLAT)
S712 1-762-875-21 SWITCH, KEYBOARD (SURROUND)
S713 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S714 1-762-875-21 SWITCH, KEYBOARD (SUPER WOOFER)
S715 1-762-875-21 SWITCH, KEYBOARD (SUPER WOOFER MODE)
S716 1-762-875-21 SWITCH, KEYBOARD (GUITAR)
S717 1-762-875-21 SWITCH, KEYBOARD (JAZZ)
S718 1-762-875-21 SWITCH, KEYBOARD (SAMBA)
S719 1-762-875-21 SWITCH, KEYBOARD (DANCE)
S720 1-762-875-21 SWITCH, KEYBOARD (TANGO)
S721 1-762-875-21 SWITCH, KEYBOARD (SALSA)
S722 1-762-875-21 SWITCH, KEYBOARD (GAME)
S723 1-762-875-21 SWITCH, KEYBOARD (b)
S724 1-762-875-21 SWITCH, KEYBOARD (v)
S725 1-762-875-21 SWITCH, KEYBOARD (V)
S726 1-762-875-21 SWITCH, KEYBOARD (B)
S727 1-762-875-21 SWITCH, KEYBOARD (ROCK)
S728 1-762-875-21 SWITCH, KEYBOARD (MOVIE)
S729 1-762-875-21 SWITCH, KEYBOARD (REGGAE)
S730 1-762-875-21 SWITCH, KEYBOARD (MIC GUITAR/KARAOKE)
S731 1-762-875-21 SWITCH, KEYBOARD (GUITAR DISTORTION)
S732 1-762-875-21 SWITCH, KEYBOARD (PTY) (AEP, UK)
S736 1-473-392-11 ENCODER, ROTARY (VOLUME)
**************************************************************
SUB TRANS BOARD
****************
< CAPACITOR >
0 C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
* CN902 1-564-321-21 PIN, CONNECTOR 2P (US, CND, AEP, UK, MX)
CN902 1-568-106-11 PIN, CONNECTOR 4P (E2, EA, SP, AR)
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
< RELAY >
0 RY901 1-755-276-11 RELAY, POWER
< SWITCH >
0 S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(E2, EA, SP, AR)
< TRANSFORMER >
0 T901 1-435-826-11 TRANSFORMER, POWER (US, CND)
0 T901 1-435-827-11 TRANSFORMER, POWER (AEP, UK)
0 T901 1-437-331-11 TRANSFORMER, POWER (E)
**************************************************************
* 1-659-058-13 TABLE SENSOR BOARD
*******************
< PHOTO INTERRUPTER >
IC202 8-749-924-18 PHOTO INTERRUPTER RPI-1391
< RESISTOR >
R207 1-249-416-11 CARBON 820 5% 1/4W
**************************************************************
PANEL VR SUB TRANS TABLE SENSOR
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
