Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
78
HCD-XG60/XG500
TC-A BOARD
***********
< LED >
D621 8-719-058-03 LED SEL5423E-TP15 (H)
D622 8-719-058-03 LED SEL5423E-TP15 (h)
< RESISTOR >
R681 1-249-411-11 CARBON 330 5% 1/4W
R682 1-249-413-11 CARBON 470 5% 1/4W
R683 1-249-414-11 CARBON 560 5% 1/4W
R684 1-249-415-11 CARBON 680 5% 1/4W
R685 1-249-417-11 CARBON 1K 5% 1/4W
R686 1-249-418-11 CARBON 1.2K 5% 1/4W
R687 1-249-403-11 CARBON 68 5% 1/4W
R688 1-249-403-11 CARBON 68 5% 1/4W
< VARIABLE RESISTOR >
RV601 1-225-739-11 RES, VAR CARBON 50K (GUITAR LEVEL)
RV602 1-225-739-11 RES, VAR CARBON 50K (MIC LEVEL)
< SWITCH >
S621 1-762-875-21 SWITCH, KEYBOARD (H)
S622 1-762-875-21 SWITCH, KEYBOARD (h)
S623 1-762-875-21 SWITCH, KEYBOARD (x)
S624 1-762-875-21 SWITCH, KEYBOARD (. AMS > m)
S625 1-762-875-21 SWITCH, KEYBOARD (. AMS > M)
S626 1-762-875-21 SWITCH, KEYBOARD (DOLBY NR)
S627 1-762-875-21 SWITCH, KEYBOARD (DIRECTION)
**************************************************************
TC-B BOARD
***********
< LED >
D611 8-719-058-03 LED SEL5423E-TP15 (h)
D612 8-719-058-03 LED SEL5423E-TP15 (H)
D613 8-719-057-97 LED SEL5923A-TP15 (X)
D614 8-719-058-04 LED SEL5223S-TP15 (z REC)
< SWITCH >
S621 1-762-875-21 SWITCH, KEYBOARD (H)
S622 1-762-875-21 SWITCH, KEYBOARD (h)
S623 1-762-875-21 SWITCH, KEYBOARD (x)
S624 1-762-875-21 SWITCH, KEYBOARD (. AMS > m)
S625 1-762-875-21 SWITCH, KEYBOARD (. AMS > M)
S626 1-762-875-21 SWITCH, KEYBOARD (DOLBY NR)
S627 1-762-875-21 SWITCH, KEYBOARD (DIRECTION)
**************************************************************
TRANS BOARD
************
1-533-217-31 HOLDER, FUSE
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C834 1-130-777-00 MYLAR 0.1uF 10% 100V
C893 1-130-777-00 MYLAR 0.1uF 10% 100V
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
TC-A TC-B TRANS
C961 1-162-306-11 CERAMIC 0.01uF 30% 16V
C963 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
* CN951 1-564-214-11 PIN, CONNECTOR (B3PS-VH) 3P (XG60)
* CN952 1-564-526-11 PLUG, CONNECTOR 11P
< DIODE >
D832 8-719-510-68 DIODE D5SBA204101
< FUSE >
0 F951 1-532-506-31 FUSE (T6.3AL/250V) (E2, EA, SP, AR)
0 F961 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250V)
(XG60)
0 F962 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250V)
(XG60)
0 F963 1-532-506-31 FUSE (T6.3AL/250V) (AEP, UK, E)
0 F963 1-533-310-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(6.3A/125V) (US, CND)
0 F964 1-532-506-31 FUSE (T6.3AL/250V) (AEP, UK, E)
0 F964 1-533-310-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(6.3A/125V) (US, CND)
< RESISTOR >
0 R951 1-219-122-91 FUSIBLE 0.33 5% 1/4W F
0 R952 1-219-122-91 FUSIBLE 0.33 5% 1/4W F
0 R953 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
R961 1-219-777-91 CARBON 3.3M 10% 1/2W
(US, CND)
**************************************************************
MISCELLANEOUS
**************
4 1-769-977-11 WIRE (FLAT TYPE) (13 CORE)
(EXCEPT AEP, UK)
4 1-773-009-11 WIRE (FLAT TYPE) (15 CORE) (AEP, UK)
5 1-693-481-11 TUNER PACK (FM/AM TUNER UNIT) (US)
5 1-693-484-11 TUNER PACK (FM/AM TUNER UNIT) (E2)
5 1-693-486-11 TUNER PACK (FM/AM TUNER UNIT) (CND)
5 1-693-488-11 TUNER PACK (FM/AM TUNER UNIT) (EA, SP,
MX, AR)
5 1-693-490-11 TUNER PACK (FM/AM TUNER UNIT) (AEP, UK)
6 1-535-706-21 PLUG, JUMPER (XG60: MX/XG500)
72 1-773-056-11 WIRE (FLAT TYPE) (17 CORE)
73 1-773-032-11 WIRE (FLAT TYPE) (15 CORE)
109 1-751-688-11 WIRE (FLAT TYPE) (13 CORE)
112 1-773-150-11 WIRE (FLAT TYPE) (21 CORE)
151 1-790-287-11 WIRE (FLAT TYPE) (19 CORE)
0 153 1-575-653-11 CORD, POWER (MX)
0 153 1-777-071-81 CORD, POWER (AEP, UK, EA, SP)
0 153 1-783-820-11 CORD, POWER (US, CND)
0 153 1-783-941-12 CORD, POWER (AR)
0 153 1-791-901-11 CORD, POWER (E2)
465 1-454-887-21 SOLENOID, PLUNGER
507 1-452-925-21 MAGNET ASSY
0 601 8-820-020-02 OPTICAL PICK-UP KSS-213D/Q-RP
602 1-782-817-11 WIRE (FLAT TYPE) (16 CORE)
HP101 A-2004-778-A BASE (A) ASSY, HEAD
HRPE101A-2004-779-A BASE (B) ASSY, HEAD
