Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
79
HCD-XG60/XG500
M1 X-3378-246-1 MOTOR ASSY (CAPSTAN) (TAPE)
M101 X-4917-523-3 MOTOR ASSY (SPINDLE) (CD)
M102 X-4917-504-1 MOTOR ASSY (SLED) (CD)
M201 A-4660-977-A MOTOR ASSY (TABLE) (CD)
M901 1-763-072-11 FAN, D. C. (EXCEPT AEP, UK)
0 T951 1-433-606-11 TRANSFORMER, POWER (XG60)
0 T951 1-435-797-11 TRANSFORMER, POWER (US, CND)
0 T951 1-435-798-11 TRANSFORMER, POWER (AEP, UK)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-871-01 SCREW +BVTT 3X6 (S)
#2 7-685-872-09 SCREW +BVTT 3X8 (S)
#3 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#5 7-685-881-09 SCREW +BVTT 4X8 (S)
#11 7-628-254-05 SCREW +PS 2.6X5
#12 7-685-781-09 SCREW +PTT 2X4 (S)
#13 7-623-921-01 RING, RETAINING, CAPSTAN
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
0 1-569-008-21 ADAPTOR, CONVERSION 2P (EA, SP)
0 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
