Sony MVC-FD91

— 4 —
1-3. Camera System Adjustments .........................................5-10
1. Picture Frame Setting ....................................................5-10
2. HALL Adjustment .........................................................5-11
3. Flange Back Adjustment ...............................................5-11
4. Flange Back Check........................................................5-12
5. Light Level Adjustment .................................................5-12
6. Auto White Balance Standard Data Input .....................5-13
7. Auto White Balance Adjustment ...................................5-13
8. Color Reproduction Adjustment....................................5-14
9. White Balance Check ....................................................5-15
10. Strobe Light Level Adjustment .....................................5-15
11. Strobe White Balance Adjustment.................................5-16
12. Strobe Light Level and White Balance Check ..............5-16
13. Steady Shot Adjustment ................................................5-17
13-1. Steady Shot Adjustment (1)...........................................5-17
13-2. Steady Shot Adjustment (2)...........................................5-18
14. CCD Defect Compensation ...........................................5-19
14. CCD Defect Compensation Check ................................5-19
1-4. Color Electronic Viewfinder System Adjustment..........5-20
1. EVF Initial Data Input ...................................................5-20
2. VCO Adjustment (VF-131 board) .................................5-21
3. Bright Adjustment (VF-131 board) ...............................5-21
4. Contrast Adjustment (VF-131 board) ............................5-22
5. Backlight Consumption Current Adjustment
(VF-131 board) ..............................................................5-22
6. White Balance Adjustment (VF-131 Board) .................5-23
1-5. LCD System Adjustment ...............................................5-24
1. LCD Initial Data Input ..................................................5-24
2. VCO Adjustment (PK-45 board) ...................................5-25
3. D range Adjustment (PK-45 board)...............................5-25
4. Bright Adjustment (PK-45 board) .................................5-26
5. Contrast Adjustment (PK-45 board) ..............................5-26
6. Color Adjustment (PK-45 board) ..................................5-27
7. V-COM Level Adjustment (PK-45 board) ....................5-27
8. V-COM Adjustment (PK-45 board) ..............................5-28
9. White Balance Adjustment (PK-45 board)....................5-28
1-6. System Control System Adjustment ..............................5-29
1. Battery End Adjustment (FC-67 board) ........................5-29
2. Alignment Check (FDD Unit) .......................................5-30
5-2. Service Mode.................................................................5-31
2-1. Adjustment Remote Commander ..................................5-31
1. Using the Adjustment Remote Commander ..................5-31
2. Precautions upon using the adjustment remote
commander ....................................................................5-31
2-2. Data Process ..................................................................5-32
2-3. Service Mode.................................................................5-33
1. Setting the Test Mode ....................................................5-33
2. Bit value discrimination ................................................5-33
3. Switch Check (1) ...........................................................5-33
4. Switch Check (2) ...........................................................5-34
5. Self Diagnosis Log Check .............................................5-34
6. REPAIR PARTS LIST
6-1. Exploded Views ...............................................................6-1
6-1-1.Cabinet (RL) Section.......................................................6-1
6-1-2.EVF Section ....................................................................6-2
6-1-3.Cabinet (Front) Section ...................................................6-3
6-1-4.Cabinet (Rear) Section ....................................................6-4
6-1-5.LCD Panel Section ..........................................................6-5
6-1-6.Lens Block Section..........................................................6-6
6-2. Electrical Parts List .........................................................6-7
* The color reproduction frame is shown on page 185.
