STR-DA5000ES
Pin No. Pin Name I/O Description
60 BCKI I Bit clock signal (2.8224 MHz) input from the digital signal processor
61 VDD — Power supply terminal (+3.3V)
62 VSS — Ground terminal
63 DLDRI I Audio serial data input from the digital signal processor
64 CSWI I Audio serial data input from the digital signal processor
65 SLSRI I Audio serial data input from the digital signal processor
66 FLFRI I Audio serial data input from the digital signal processor
67 TEST3 I Test mode setting terminal Not used
68 CLK512 I Serial data transfer clock signal input terminal
69 VSS — Ground terminal
70 XRST I Reset signal input from the main system controller
71 VDD — Power supply terminal (+3.3V)
72 SCLK I Serial data transfer clock signal input from the main system controller
73 XCS I Chip select signal input from the main system controller
74 SI I Serial data input from the main system controller
75 SO O Serial data output to the main system controller
76 DEXRI I Not used (connected to ground)
77 DMLI I SBL-ch analog audio signal input terminal
78 DMRI I SBR-ch analog audio signal input terminal
79 VSS — Ground terminal
80 PHRI I Clock signal input terminal
81 BCKAI I Bit clock signal input from the GPR
82 DQM O Not used
83 DLI I L-ch analog audio signal input terminal
84 DRI I R-ch analog audio signal input terminal
85 DCI I C-ch analog audio signal input terminal
86 DLFEI I W-ch analog audio signal input terminal
87 DLSI I SL-ch analog audio signal input terminal
88 DRSI I SR-ch analog audio signal input terminal
89 VSS — Ground terminal
90 to 95 D15 to D10 I/O Serial data input/output terminal with the DRAM
96 VDD — Power supply terminal (+3.3V)
97, 98 D9, D8 I/O Serial data input/output terminal with the DRAM
99 VSS — Ground terminal
100 D0 I/O Serial data input/output terminal with the DRAM
