STR-DA5000ES
DIGITAL BOARD IC2301 CXD9722TQ (LIP SYNC ADJUST)
Pin No. Pin Name I/O Description
1 to 5 D1 to D5 I/O Serial data input/output terminal with the DRAM
6 VDD Power supply terminal (+3.3V)
7, 8 D6, D7 I/O Serial data input/output terminal with the DRAM
9 VSS Ground terminal
10 WE O Write enable signal output to the DRAM
11 CAS O Column address strobe signal output to the DRAM
12 RAS O Row address strobe signal output to the DRAM
13 CS O Chip select signal output to the DRAM
14 CLK O Serial data transfer clock signal output to the DRAM
15 CEK O Chip enable signal output to the DRAM
16 VDD Power supply terminal (+3.3V)
17, 18 A11, A10 O Address signal output to the DRAM
19 to 22 A0 to A3 O Address signal output to the DRAM
23 VSS Ground terminal
24 to 29 A9 to A4 O Address signal output to the DRAM
30 VSS Ground terminal
31 DRSO O SR-ch analog audio signal output terminal
32 DLSO O SL-ch analog audio signal output terminal
33 DEXRO O Not used (open)
34 DLFEO O W-ch analog audio signal output terminal
35 DCO O C-ch analog audio signal output terminal
36 VDD O Power supply terminal (+3.3V)
37 DRO O R-ch analog audio signal output terminal
38 DLO O L-ch analog audio signal output terminal
39 VSS Ground terminal
40 DMRO O SBR-ch analog audio signal output terminal
41 DMLO O SBL-ch analog audio signal output terminal
42 VSS Ground terminal
43 VDD Power supply terminal (+3.3V)
44 DLDRO O Audio serial data output terminal
45 CSWO O Audio serial data output terminal
46 SLSRO O Audio serial data output terminal
47 FLFRO O Audio serial data output terminal
48 VSS Ground terminal
49 SPDIFO O SPDIF signal output terminal Not used
50 TEST1 I Test mode setting terminal Not used
51 TRST I Reset signal input terminal for test Not used
52 TMS I Mode setting terminal for test Not used
53 TCK I Clock signal input terminal for test Not used
54 TDI I Serial data input terminal for test Not used
55 TDO O Serial data output terminal for test Not used
56 TEST2 I Test mode setting terminal Not used
57 SPDIFI I SPDIF signal input terminal Not used
58 VSS Ground terminal
59 LRCKI I L/R sampling clock signal (44.1 kHz) input from the digital signal processor
