98
STR-DA5000ES
• DIGITAL BOARD IC2401, IC2426 ISPLSI2032VE-110LTN44-MOD (GPR)
Pin No. Pin Name I/O Description
1EDGE I Clock signal input terminal
2 BCKIN I Bit clock signal input terminal
3 BCK2IN I Not used (open)
4 I/O I/O Not used (open)
5MCK I Serial data transfer clock signal input terminal
6 VCC — Power supply terminal (+3.3V)
7 BSCAM — Not used (open)
8 IN Q/TDI I Not used (open)
9, 10 I/O I/O Not used (open)
11 BCKAOUT O IC2401: Bit clock signal output, IC2426: Not used (open)
12 MCKOUT O Serial data transfer clock signal output terminal
13 DIOUT_8 O IC2401: SBR-ch analog audio signal output, IC2426: Not used (open)
14 DIOUT_7 O IC2401: SBL-ch analog audio signal output, IC2426: Not used (open)
15 DIOUT_6 O IC2401: SR-ch analog audio signal output, IC2426: Not used (open)
16 DIOUT_5 O IC2401: SL-ch analog audio signal output, IC2426: Not used (open)
17 GND — Ground terminal
18 IN 1/TDO O Not used (open)
19 DIOUT_4 O W-ch analog audio signal output terminal
20 DIOUT_3 O C-ch analog audio signal output terminal
21 DIOUT_2 O R-ch analog audio signal output terminal
22 DIOUT_1 O L-ch analog audio signal output terminal
23 to 26 I/O I/O Not used (open)
27 Y2/TCK — Not used (open)
28 VCC — Power supply terminal (+3.3V)
29 Y1/RESET I Reset signal input terminal
30 TMS — Not used (open)
31 DATAEN I Not used (connected to VCC)
32 CLKSEL I Not used (connected to VCC)
33 FS I IC2401: Not used (connected to ground), IC2426: Clock signal input
34 I/O I/O Not used (open)
35 DATA_1 I IC2401: L-ch analog audio signal input, IC2426: analog audio signal input
36 DATA_2 I IC2401:R-ch analog audio signal input, IC2426: analog audio signal input
37 DATA_3 I IC2401: SL-ch analog audio signal input, IC2426: analog audio signal input
38 DATA_4 I IC2401: SR-ch analog audio signal input, IC2426: analog audio signal input
39 GND — Ground terminal
40 GOE0 — Not used (open)
41 DATA_5 I IC2401: C-ch analog audio signal input, IC2426: Not used (open)
42 DATA_6 I IC2401: W-ch analog audio signal input, IC2426: Not used (open)
43 DATA_7 I IC2401: SBL-ch analog audio signal input, IC2426: Not used (open)
44 DATA_8 I IC2401: SBR-ch analog audio signal inputl, IC2426: Not used (connected to ground)
