STR-DA5000ES
Pin No. Pin Name I/O Description
46 FUNCLAT O Serial data latch pulse output to the TC74HCT7007AF
47 D.MIXLAT O Serial data latch pulse output to the TC74HCT7007AF
48 VDLLAT O Serial data latch pulse output to the TC74HCT7007AF
49 UPCONLAT O Serial data latch pulse output terminal Not used
50 MBUS-STS0 I M-BUS status input from the sub system controller
51 A1OUT O Sircs signal output for the CTRL A1 II
52 MD2 I Setting terminal for the CPU operational mode
53 MD1 I Setting terminal for the CPU operational mode
54 MD0 I Setting terminal for the CPU operational mode
55 RSTX I External reset signal input terminal
56 VCC — Power supply terminal (+3.3V)
57 X1 I Main system clock input terminal (16.5 MHz)
58 X0 O Main system clock output terminal (16.5 MHz)
59 VSS — Ground terminal
60 A1IN I Sircs signal input for the CTRL A1 II
61 SIRCS IN I SIRCS signal input terminal
62 POWER SW I Power switch input terminal
63 RDSCLK I RDS serial data transfer clock signal input from the tuner unit
64 MBUS-STS1 I Strobe control signal input from the sub system controller
65 MBUS-STS2 I M-BUS status input from the sub system controller
66 MBUS-STS3 I M-BUS status input from the sub system controller
67 MBUS-STS4 I M-BUS status input from the sub system controller
68 VCC — Power supply terminal (+3.3V)
69 RST TRG O Reset signal output to the terminal
70 END FLAG O End flag output to the sub system controller
71 A1-LAT O Serial data latch pulse output to the sub system controller
72 TUNLAT O Serial data latch pulse output to the tuner unit
73 TUNED I Tuning detection signal input from the tuner unit
74 STEREO I FM stereo detection signal input from the tuner unit
75 TUNDO I Serial data input from the tuner unit
76 PREOUT-RY O Relay drive signal output terminal Not used
77 VCC — Power supply terminal (+3.3V)
78 STOP I AC off detection signal input terminal
79 POWRY O Relay drive signal output terminal (for main power) “H”: relay on
80 P.CHANGE O Tuner auto stop signal output terminal
81 RDSDATA I RDS serial data input from the tuner unit
82 PREVOL-LAT O Serial data latch pulse output terminal Not used
83 AD/SUB-RST O Reset signal output to the sub-2 system controller “L”: rese
84 S-MUTE O Muting on/off control signal output terminal
85
SUB-U
CONTROL
O Clock signal output to the sub-2 system controller
86 SUB-U INFO2 I Serial data input from the sub-2 system controller
87 SUB-U INFO1 O Serial data output to the sub-2 system controller
88 FUNCJOG1 I Jog dial pulse input from the rotary encoder (for INPUT SELECTOR)
89 FUNCJOG2 I Jog dial pulse input from the rotary encoder (for INPUT SELECTOR)
90 VOLJOG1 I Jog dial pulse input from the rotary encoder (for MASTER VOLUME)
