103
STR-DA5000ES
Pin No. Pin Name I/O Description
91 VOLJOG2 I Jog dial pulse input from the rotary encoder (for MASTER VOLUME)
92 BASSJOG1 I Jog dial pulse input from the rotary encoder (for BASS)
93 BASSJOG2 I Jog dial pulse input from the rotary encoder (for BASS)
94 OSDLAT O Serial data latch pulse output to the OSD
95 FLLAT O Serial data latch pulse output to the fluorescent display tube
96 FLCLR O Clear signal output to the fluorescent display tube
97 VCC — Power supply terminal (+3.3V)
98 VSS — Ground terminal
99 SDA I/O Two-way data bus with the EEPROM
100 SCL O Serial data transfer clock signal output to the EEPROM
101 VSS — Ground terminal
102 OSD-CLK O Serial data transfer clock signal output to the OSD
103 OSD-DAT O Serial data output to the OSD
104 OSD-VSINC I Not used
105 TREJOG1 I Jog dial pulse input from the rotary encoder (for TREBLE)
106 TREJOG2 I Jog dial pulse input from the rotary encoder (for TREBLE)
107 IICDATA I/O IIC two-way data bus with the chroma decoder
108 IICCLK O IIC bus clock signal output to the choma decoder
109 SOT1 O Serial data output to the RS-232C
110 SIN1 I Serial data input from the RS-232C
111 FLCLK O Serial data transfer clock signal output to the fluorescent display tube
112 FLDATA O Serial data output to the fluorescent display tube
113 DAC-LAT O Serial data latch pulse signal output to the D/A converter Not used
114 DAC-RST O Reset signal output to the D/A converter “H”: reset Not used
115
DAC-DATA
(UCOM-IN)
I Serial data input from the D/A converter Not used
116 SP-A I Speaker switch input terminal
117 SP-B I Speaker switch input terminal
118 MENU JOG1 I Jog dial pulse input from the rotary encoder (for MENU)
119 MENU JOG2 I Jog dial pulse input from the rotary encoder (for MENU)
120 PAGE JOG1 I Jog dial pulse input from the rotary encoder (for MAIN MENU)
121 PAGE JOG2 I Jog dial pulse input from the rotary encoder (for MAIN MENU)
122 VCC — Power supply terminal (+3.3V)
123 LED LAT O Serial data latch pulse output to the data decoder/LED driver
124 LED CLR O Serial data transfer clock signal output to the data decoder/LED driver
125 PCMSEL O Output clock selection signal output to the D-OUT switch
126 DAVS (VSS) — Ground terminal (for digital)
127 DAVC (VCC) — Power supply terminal (+3.3V) (for digital)
128 AVCC (VCC) — Power supply terminal (+3.3V) (for analog)
129 AVRH (VCC) — Reference voltage (+3.3V) input terminal (for analog)
130 AVRL (VSS) — Ground terminal (for analog)
131 AVSS (VSS) — Ground terminal (for analog)
132 AD1 I Key function A/D input
133 AD2 I Key function A/D input
134 AD3 I Key function A/D input
135 VERSION I Version set terminal
