Sony STR-DA5000ES - Page 152

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
152
STR-DA5000ES
FL FUNCTION HP JOG KEY
R1028 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R1029 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R1030 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1031 1-216-073-00 RES-CHIP 1K 5% 1/10W
R1032 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1033 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R1034 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R1035 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1036 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1037 1-216-025-11 RES-CHIP 100 5% 1/10W
R1038 1-216-025-11 RES-CHIP 100 5% 1/10W
R1039 1-216-081-00 RES-CHIP 22K 5% 1/10W
R1040 1-216-295-00 SHORT CHIP 0
< SWITCH >
S1001 1-771-349-21 SWITCH, KEYBOARD
(SURR BACK DECODING)
S1002 1-771-349-21 SWITCH, KEYBOARD (MULTI CH IN 1/2)
S1003 1-771-349-21 SWITCH, KEYBOARD (DIRECT)
S1004 1-771-349-21 SWITCH, KEYBOARD (DECODE PRIORITY)
S1005 1-771-349-21 SWITCH, KEYBOARD (DISPLAY)
S1006 1-771-349-21 SWITCH, KEYBOARD (USER PRESET)
S1007 1-771-349-21 SWITCH, KEYBOARD (MEMORY/ENTER)
S1008 1-771-349-21 SWITCH, KEYBOARD (FM/AM)
S1009 1-771-349-21 SWITCH, KEYBOARD (TUNING +)
S1010 1-771-349-21 SWITCH, KEYBOARD (TUNING –)
S1011 1-771-349-21 SWITCH, KEYBOARD (PRESET TUNING +)
S1012 1-771-349-21 SWITCH, KEYBOARD (PRESET TUNING –)
< TRANSFORMER >
T1001 1-439-837-11 TRANSFORMER, DC-DC CONVERTER
(EXCEPT AEP: BLACK)
T1001 1-439-838-11 TRANSFORMER, DC-DC CONVERTER
(AEP: BLACK)
************************************************************
1-688-726-11 FUNCTION BOARD
**************
< CONNECTOR >
* CN1005 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
< RESISTOR >
R1055 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
< ROTARY ENCODER >
RV1006 1-418-589-11 ENCODER, ROTARY (INPUT SELECTOR)
< SWITCH >
S1014 1-771-349-21 SWITCH, KEYBOARD (INPUT MODE)
************************************************************
1-688-723-11 HP BOARD
*********
< CAPACITOR >
C1025 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1026 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C1027 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C1041 1-165-319-11 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
* CN1011 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
CN1012 1-779-978-11 PIN, CONNECTOR 3P
< JACK >
J1001 1-815-313-21 JACK (PHONES)
< SHORT >
JW1011 1-216-295-00 SHORT CHIP 0
JW1012 1-216-295-00 SHORT CHIP 0
JW1013 1-216-295-00 SHORT CHIP 0
JW1014 1-216-295-00 SHORT CHIP 0
************************************************************
1-688-724-11 JOG BOARD
*********
< CONNECTOR >
CN1013 1-785-820-11 CONNECTOR, BOARD TO BOARD 15P
< DIODE >
D1025 8-719-988-61 DIODE 1SS355TE-17
D1026 8-719-988-61 DIODE 1SS355TE-17
< RESISTOR >
R1043 1-216-089-11 RES-CHIP 47K 5% 1/10W
R1044 1-216-089-11 RES-CHIP 47K 5% 1/10W
R1045 1-216-089-11 RES-CHIP 47K 5% 1/10W
R1046 1-216-089-11 RES-CHIP 47K 5% 1/10W
< ROTARY ENCODER >
RV1001 1-478-017-11 ENCODER, ROTARY (BASS)
RV1002 1-478-017-11 ENCODER, ROTARY (TREBLE)
RV1003 1-478-017-11 ENCODER, ROTARY (MAIN MENU)
RV1004 1-478-017-11 ENCODER, ROTARY (MENU)
RV1005 1-478-017-11 ENCODER, ROTARY (-/+)
< SWITCH >
SW1001 1-762-684-11 SWITCH, ROTARY (SPEAKERS)
************************************************************
1-688-729-11 KEY BOARD
**********
< RESISTOR >
R1056 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R1057 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R1058 1-216-049-11 RES-CHIP 1K 5% 1/10W
< SWITCH >
S1015 1-771-349-21 SWITCH, KEYBOARD (MUSIC)
S1016 1-771-349-21 SWITCH, KEYBOARD (MOVIE)
S1017 1-771-349-21 SWITCH, KEYBOARD (A.F.D.)
S1018 1-771-349-21 SWITCH, KEYBOARD (2CH)
************************************************************
