Sony STR-DA5000ES - Page 153

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
153
STR-DA5000ES
LED POWER SW POWER SW SUB PRE-OUT
1-688-731-11 LED BOARD
**********
< CONNECTOR >
CN1021 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
< LED >
D1014 8-719-313-66 LED SEL6410E-TH12 (DIRECT)
< RESISTOR >
R1025 1-216-029-00 RES-CHIP 150 5% 1/10W
************************************************************
A-4733-995-A POWER SW BOARD, COMPLETE
****************
< CAPACITOR >
C1023 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C1024 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
< CONNECTOR >
* CN1010 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN1022 1-506-481-11 CONNECTOR PIN 2P
< DIODE >
D1020 8-719-059-14 LED SID313BP-TP19 (IR RECEPTOR)
D1021 8-719-075-86 LED SID307BRTP19 (IR RECEPTOR)
D1022 8-719-075-86 LED SID307BRTP19 (IR RECEPTOR)
D1023 8-719-988-61 DIODE 1SS355TE-17
D1024 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC1005 8-759-242-70 IC TC7WU04F
< TRANSISTOR >
Q1003 8-729-801-93 TRANSISTOR 2SD1387-3
Q1004 8-729-801-93 TRANSISTOR 2SD1387-3
< RESISTOR >
R1041 1-216-298-00 RES-CHIP 2.2 5% 1/10W
R1042 1-216-298-00 RES-CHIP 2.2 5% 1/10W
************************************************************
1-860-316-11 POWER SW SUB BOARD
******************
< SWITCH >
S1013 1-771-349-21 SWITCH, KEYBOARD (I/1)
************************************************************
A-4734-012-A PRE-OUT BOARD, COMPLETE (US, CND)
************************
< CAPACITOR >
C2801 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2802 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2805 1-126-395-11 ELECT CHIP 22uF 20% 16V
C2806 1-126-395-11 ELECT CHIP 22uF 20% 16V
C2815 1-128-858-11 ELECT 22uF 20% 50V
C2816 1-128-832-11 ELECT 220uF 20% 10V
C2817 1-137-505-11 MYLAR 220PF 5% 100V
C2818 1-128-858-11 ELECT 22uF 20% 50V
C2819 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2822 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C2823 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C2824 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C2834 1-216-295-00 SHORT CHIP 0
C2835 1-128-858-11 ELECT 22uF 20% 50V
C2836 1-128-832-11 ELECT 220uF 20% 10V
C2837 1-137-505-11 MYLAR 220PF 5% 100V
C2838 1-128-858-11 ELECT 22uF 20% 50V
C2839 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2851 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2865 1-128-858-11 ELECT 22uF 20% 50V
C2866 1-128-832-11 ELECT 220uF 20% 10V
C2867 1-137-505-11 MYLAR 220PF 5% 100V
C2868 1-128-858-11 ELECT 22uF 20% 50V
C2869 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2872 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C2873 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C2874 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C2884 1-216-295-00 SHORT CHIP 0
C2885 1-128-858-11 ELECT 22uF 20% 50V
C2886 1-128-832-11 ELECT 220uF 20% 10V
C2887 1-137-505-11 MYLAR 220PF 5% 100V
C2888 1-128-858-11 ELECT 22uF 20% 50V
C2889 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2901 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2915 1-128-858-11 ELECT 22uF 20% 50V
C2916 1-128-832-11 ELECT 220uF 20% 10V
C2917 1-137-505-11 MYLAR 220PF 5% 100V
C2918 1-128-858-11 ELECT 22uF 20% 50V
C2919 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2922 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C2923 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C2924 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C2934 1-216-295-00 SHORT CHIP 0
C2935 1-128-858-11 ELECT 22uF 20% 50V
C2936 1-128-832-11 ELECT 220uF 20% 10V
C2937 1-137-505-11 MYLAR 220PF 5% 100V
C2938 1-128-858-11 ELECT 22uF 20% 50V
C2939 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2951 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2965 1-128-858-11 ELECT 22uF 20% 50V
C2966 1-128-832-11 ELECT 220uF 20% 10V
C2967 1-137-505-11 MYLAR 220PF 5% 100V
C2968 1-128-858-11 ELECT 22uF 20% 50V
C2969 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2972 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C2973 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C2974 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C2983 1-216-295-00 SHORT CHIP 0
C2985 1-128-858-11 ELECT 22uF 20% 50V
C2986 1-128-832-11 ELECT 220uF 20% 10V
C2987 1-137-505-11 MYLAR 220PF 5% 100V
