Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
162
STR-DA5000ES
VIDEO
C3719 1-119-820-11 ELECT 1uF 20% 50V
C3720 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C3721 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C3722 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C3724 1-127-718-91 ELECT 100uF 20% 16V
C3725 1-128-840-11 ELECT 47uF 20% 16V
C3726 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C3731 1-126-962-11 ELECT 3.3uF 20% 50V
C3732 1-127-718-91 ELECT 100uF 20% 16V
C3733 1-126-916-11 ELECT 1000uF 20% 6.3V
C3734 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C3741 1-119-823-11 ELECT 4.7uF 20% 50V
C3743 1-119-823-11 ELECT 4.7uF 20% 50V
C3744 1-128-858-11 ELECT 22uF 20% 50V
C3745 1-127-718-91 ELECT 100uF 20% 16V
C3746 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C3751 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C3752 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C3753 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C3801 1-127-718-91 ELECT 100uF 20% 16V
C3802 1-136-169-00 MYLAR 0.22uF 5% 50V
C3803 1-127-718-91 ELECT 100uF 20% 16V
C3804 1-136-169-00 MYLAR 0.22uF 5% 50V
C3805 1-127-718-91 ELECT 100uF 20% 16V
C3806 1-136-169-00 MYLAR 0.22uF 5% 50V
C3811 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C3812 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C3813 1-165-319-11 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
CN3801 1-794-003-11 CONNECTOR 15P
CN3802 1-568-826-11 CONNECTOR, FFC 7P (US, CND)
CN3803 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CN3804 1-784-778-11 CONNECTOR, FFC 17P
CN3806 1-794-002-11 CONNECTOR 13P
< TRIMMER >
CT3501 1-141-442-91 CAP, CERAMIC TRIMMER
CT3502 1-141-442-91 CAP, CERAMIC TRIMMER (US, CND, TW)
CT3503 1-141-442-91 CAP, CERAMIC TRIMMER (AEP, CH)
CT3504 1-141-442-91 CAP, CERAMIC TRIMMER (AEP, CH)
< DIODE >
D3301 8-719-988-61 DIODE 1SS355TE-17
D3302 8-719-988-61 DIODE 1SS355TE-17
D3303 8-719-988-61 DIODE 1SS355TE-17
D3311 8-719-988-61 DIODE 1SS355TE-17
D3312 8-719-988-61 DIODE 1SS355TE-17
D3421 8-719-988-61 DIODE 1SS355TE-17 (US, CND)
D3422 8-719-988-61 DIODE 1SS355TE-17 (US, CND)
D3731 8-719-988-61 DIODE 1SS355TE-17
D3732 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB3201 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3501 1-469-152-11 FERRITE, EMI (SMD) (2012) (AEP, CH)
FB3502 1-414-813-11 FERRITE, EMI (SMD) (2012) (AEP, CH)
FB3601 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3602 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3603 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3661 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3751 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3801 1-469-152-11 FERRITE, EMI (SMD) (2012)
< FILTER >
FL3621 1-239-847-11 FILTER, LOW PASS
FL3631 1-239-847-11 FILTER, LOW PASS
< IC >
IC3201 8-759-663-90 IC ADM3222ARU-REEL
IC3311 8-759-822-05 IC LA7213
IC3321 8-759-663-94 IC LA7106M-TLM
IC3421 8-759-536-24 IC NJM-2296M-TE2 (US, CND)
IC3431 8-759-536-24 IC NJM-2296M-TE2
IC3451 8-759-177-02 IC NJM2267M (TE2)
IC3501 6-700-367-01 IC MB90089PF-G-238-BND
IC3502 8-759-032-01 IC MC74HC00AF (AEP, CH)
IC3503 8-759-242-70 IC TC7WU04F (AEP, CH)
IC3521 8-759-682-76 IC BA7622F-E2-A
IC3601 8-752-386-17 IC CXD2064Q
IC3641 8-759-177-02 IC NJM2267M (TE2)
IC3651 8-759-671-94 IC MC74HC4053AFEL
IC3661 8-759-671-94 IC MC74HC4053AFEL
IC3671 8-759-429-17 IC NJM2268V (TE2)
IC3701 8-752-109-74 IC CXA2199Q
IC3702 8-759-445-59 IC BA033T
IC3721 8-759-565-20 IC TDA4662T-V2
IC3731 8-759-822-05 IC LA7213
IC3741 8-759-429-17 IC NJM2268V (TE2)
IC3751 8-759-671-94 IC MC74HC4053AFEL
IC3811 8-759-238-47 IC TC74HCT7007AF (EL)
IC3812 8-759-233-44 IC TC74HC595AF
IC3813 8-759-233-44 IC TC74HC595AF
< CONNECTOR/JACK >
J3201 1-815-737-11 CONNECTOR, (D) SUB 9P (RS-232C)
J3202 1-563-330-11 JACK (C TRL A1 II)
J3301 1-817-601-21 JACK, PIN 3P
(COMPONENT VIDEO MONITOR OUT)
J3302 1-817-601-21 JACK, PIN 3P (COMPONENT VIDEO, TV IN)
J3303 1-817-601-21 JACK, PIN 4P (COMPONENT VIDEO, DVD IN)
J3401 1-770-337-21 JACK, PIN 3P
(MONITOR OUT VIDEO, TV/SAT VIDEOIN,
DVD VIDEO IN)
J3402 1-770-337-21 JACK, PIN 3P
(VIDEO2 VIDEO OUT, VIDEO2 VIDEO IN,
VIDEO1 VIDEO OUT)
J3403 1-774-227-21 JACK, PIN 1P
(VIDEO1 VIDEO IN) (EXCEPT US, CND)
J3403 1-794-435-11 JACK, PIN 2P
(VIDEO1 VIDEO IN, 2ND ZONE VIDEO OUT)
(US, CND)
< COIL >
L3421 1-410-482-31 MICRO INDUCTOR 100uH
(US, CND)
L3422 1-410-482-31 MICRO INDUCTOR 100uH
(US, CND)
