Sony STR-DA5000ES - Page 163

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
163
STR-DA5000ES
VIDEO
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
L3431 1-410-482-31 MICRO INDUCTOR 100uH
L3432 1-410-482-31 MICRO INDUCTOR 100uH
L3501 1-408-781-00 CHIP INDUCTOR 22uH
L3601 1-410-946-31 CHIP INDUCTOR 22uH
< TRANSISTOR >
Q3301 8-729-230-49 TRANSISTOR 2SC2712-YG
Q3302 8-729-230-49 TRANSISTOR 2SC2712-YG
Q3303 8-729-230-49 TRANSISTOR 2SC2712-YG
Q3311 1-801-806-11 TR DTC144EKA
Q3621 8-729-216-22 TRANSISTOR 2SA1162-G
Q3622 8-729-230-49 TRANSISTOR 2SC2712-YG
Q3631 8-729-216-22 TRANSISTOR 2SA1162-G
Q3632 8-729-230-49 TRANSISTOR 2SC2712-YG
Q3641 8-729-216-22 TRANSISTOR 2SA1162-G
Q3651 8-729-140-97 TRANSISTOR 2SB734-34
Q3652 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q3701 8-729-216-22 TRANSISTOR 2SA1162-G
Q3731 1-801-806-11 TR DTC144EKA
< RESISTOR >
R3201 1-216-025-11 RES-CHIP 100 5% 1/10W
R3202 1-216-025-11 RES-CHIP 100 5% 1/10W
R3301 1-216-022-00 RES-CHIP 75 5% 1/10W
R3302 1-216-022-00 RES-CHIP 75 5% 1/10W
R3303 1-216-022-00 RES-CHIP 75 5% 1/10W
R3304 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R3305 1-216-073-00 RES-CHIP 1K 5% 1/10W
R3306 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R3307 1-216-073-00 RES-CHIP 1K 5% 1/10W
R3308 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R3310 1-216-073-00 RES-CHIP 1K 5% 1/10W
R3311 1-216-037-00 RES-CHIP 330 5% 1/10W
R3312 1-216-101-00 RES-CHIP 150K 5% 1/10W
R3313 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R3314 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R3315 1-216-295-00 SHORT CHIP 0
R3316 1-216-295-00 SHORT CHIP 0
R3317 1-216-295-00 SHORT CHIP 0
0 R3318 1-249-393-11 CARBON 10 5% 1/4W F
0 R3319 1-249-393-11 CARBON 10 5% 1/4W F
R3323 1-216-073-00 RES-CHIP 1K 5% 1/10W
R3324 1-216-073-00 RES-CHIP 1K 5% 1/10W
R3325 1-216-073-00 RES-CHIP 1K 5% 1/10W
R3401 1-216-295-00 SHORT CHIP 0
R3402 1-216-295-00 SHORT CHIP 0
R3403 1-216-295-00 SHORT CHIP 0
R3404 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3405 1-216-022-00 RES-CHIP 75 5% 1/10W
R3406 1-216-022-00 RES-CHIP 75 5% 1/10W
R3407 1-216-022-00 RES-CHIP 75 5% 1/10W
R3408 1-216-022-00 RES-CHIP 75 5% 1/10W
R3409 1-216-022-00 RES-CHIP 75 5% 1/10W
R3410 1-216-022-00 RES-CHIP 75 5% 1/10W
R3411 1-216-022-00 RES-CHIP 75 5% 1/10W
R3412 1-216-022-00 RES-CHIP 75 5% 1/10W
(US, CND)
R3421 1-216-022-00 RES-CHIP 75 5% 1/10W
(US, CND)
R3422 1-216-022-00 RES-CHIP 75 5% 1/10W
(US, CND)
R3423 1-216-097-11 RES-CHIP 100K 5% 1/10W
(US, CND)
R3431 1-216-022-00 RES-CHIP 75 5% 1/10W
R3432 1-216-022-00 RES-CHIP 75 5% 1/10W
R3451 1-216-121-11 RES-CHIP 1M 5% 1/10W
R3452 1-216-121-11 RES-CHIP 1M 5% 1/10W
R3501 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R3502 1-216-035-00 RES-CHIP 270 5% 1/10W
(US, CND, TW)
R3503 1-216-025-11 RES-CHIP 100 5% 1/10W
(AEP, CH)
R3504 1-216-025-11 RES-CHIP 100 5% 1/10W
(AEP, CH)
R3505 1-216-035-00 RES-CHIP 270 5% 1/10W
(AEP, CH)
R3506 1-216-121-11 RES-CHIP 1M 5% 1/10W
(AEP, CH)
R3507 1-216-121-11 RES-CHIP 1M 5% 1/10W
(AEP, CH)
R3508 1-216-035-00 RES-CHIP 270 5% 1/10W
(AEP, CH)
R3509 1-216-025-11 RES-CHIP 100 5% 1/10W
(AEP, CH)
R3521 1-216-022-00 RES-CHIP 75 5% 1/10W
R3522 1-216-022-00 RES-CHIP 75 5% 1/10W
R3523 1-216-022-00 RES-CHIP 75 5% 1/10W
R3524 1-216-022-00 RES-CHIP 75 5% 1/10W
R3525 1-216-022-00 RES-CHIP 75 5% 1/10W
R3526 1-216-022-00 RES-CHIP 75 5% 1/10W
R3603 1-216-091-00 RES-CHIP 56K 5% 1/10W
R3604 1-216-043-00 RES-CHIP 560 5% 1/10W
R3605 1-216-061-00 RES-CHIP 3.3K 5% 1/10W
R3606 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R3607 1-216-059-00 RES-CHIP 2.7K 5% 1/10W
R3621 1-216-029-00 RES-CHIP 150 5% 1/10W
R3622 1-216-025-11 RES-CHIP 100 5% 1/10W
R3623 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3624 1-216-043-00 RES-CHIP 560 5% 1/10W
R3625 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
R3626 1-216-085-00 RES-CHIP 33K 5% 1/10W
R3627 1-216-081-00 RES-CHIP 22K 5% 1/10W
R3628 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3629 1-216-073-00 RES-CHIP 1K 5% 1/10W
R3631 1-216-029-00 RES-CHIP 150 5% 1/10W
R3632 1-216-025-11 RES-CHIP 100 5% 1/10W
R3633 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3634 1-216-043-00 RES-CHIP 560 5% 1/10W
R3635 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
R3636 1-216-085-00 RES-CHIP 33K 5% 1/10W
R3637 1-216-081-00 RES-CHIP 22K 5% 1/10W
R3638 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3639 1-216-073-00 RES-CHIP 1K 5% 1/10W
R3641 1-216-121-11 RES-CHIP 1M 5% 1/10W
R3642 1-216-121-11 RES-CHIP 1M 5% 1/10W
R3643 1-216-017-00 RES-CHIP 47 5% 1/10W
R3644 1-216-025-11 RES-CHIP 100 5% 1/10W
