Sony STR-DA5000ES - Page 164

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
164
STR-DA5000ES
VIDEO VIDEO3 VOL
R3645 1-216-033-00 RES-CHIP 220 5% 1/10W
R3646 1-216-085-00 RES-CHIP 33K 5% 1/10W
R3647 1-216-081-00 RES-CHIP 22K 5% 1/10W
R3648 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R3649 1-216-025-11 RES-CHIP 100 5% 1/10W
R3651 1-216-073-00 RES-CHIP 1K 5% 1/10W
R3652 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R3671 1-216-121-11 RES-CHIP 1M 5% 1/10W
R3701 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R3702 1-216-041-00 RES-CHIP 470 5% 1/10W
R3703 1-216-077-00 RES-CHIP 15K 5% 1/10W
R3704 1-216-089-11 RES-CHIP 47K 5% 1/10W
R3705 1-216-025-11 RES-CHIP 100 5% 1/10W
R3706 1-216-025-11 RES-CHIP 100 5% 1/10W
R3707 1-216-025-11 RES-CHIP 100 5% 1/10W
R3708 1-216-033-00 RES-CHIP 220 5% 1/10W
R3709 1-216-109-00 RES-CHIP 330K 5% 1/10W
R3710 1-216-037-00 RES-CHIP 330 5% 1/10W
R3711 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R3712 1-216-073-00 RES-CHIP 1K 5% 1/10W
R3713 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R3714 1-216-061-00 RES-CHIP 3.3K 5% 1/10W
R3715 1-216-061-00 RES-CHIP 3.3K 5% 1/10W
R3716 1-216-061-00 RES-CHIP 3.3K 5% 1/10W
R3731 1-216-037-00 RES-CHIP 330 5% 1/10W
R3732 1-216-101-00 RES-CHIP 150K 5% 1/10W
R3733 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R3734 1-216-081-00 RES-CHIP 22K 5% 1/10W
R3735 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3741 1-216-121-11 RES-CHIP 1M 5% 1/10W
< RELAY >
RY3301 1-755-359-11 RELAY
RY3302 1-755-359-11 RELAY
RY3303 1-755-359-11 RELAY
RY3304 1-755-359-11 RELAY
RY3305 1-755-359-11 RELAY
RY3306 1-755-359-11 RELAY
< CONNECTOR >
TP3501 1-784-921-11 PIN, CONNECTOR 4P
< VIBRATOR >
X3501 1-781-821-21 VIBRATOR, CRYSTAL (14.31MHz)
(US, CND, TW)
X3502 1-781-821-21 VIBRATOR, CRYSTAL (14.31MHz) (AEP, CH)
X3503 1-781-820-21 VIBRATOR, CRYSTAL (17.437MHz) (AEP, CH)
X3701 1-781-342-21 OSCILLATOR, CRYSTAL (3.5795MHz)
X3702 1-781-134-21 VIBRATOR, CRYSTAL (4.43MHz)
X3703 1-577-611-11 OSCILALTOR, CERAMIC (500kHz)
************************************************************
A-4733-994-A VIDEO3 BOARD, COMPLETE
***********************
< CAPACITOR/SHORT >
C1028 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1029 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C1030 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C1032 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C1035 1-216-295-00 SHORT CHIP 0
C1036 1-216-295-00 SHORT CHIP 0
C1037 1-216-295-00 SHORT CHIP 0
< CONNECTOR >
* CN1019 1-564-728-11 PIN, CONNECTOR (SMALL TYPE) 12P
< GROUND TERMINAL >
* EB1002 1-537-738-21 TERMINAL, EARTH
< IC >
IC1006 6-600-219-01 IC GP1FM313RZ0F
(VIDEO3 INPUT, VIDEO3 OPTICAL)
< JACK/TERMINAL >
J1002 1-770-571-11 JACK BLOCK, PIN (L TYPE) 3P
(VIDEO3 INPUT, VIDEO3 VIDEO/AUDIO)
J1003 1-784-808-11 TERMINAL, S (VIDEO3 INPUT, S2 VIDEO)
< RESISTOR >
R1047 1-216-025-11 RES-CHIP 100 5% 1/10W
R1048 1-216-025-11 RES-CHIP 100 5% 1/10W
R1049 1-216-025-11 RES-CHIP 100 5% 1/10W
R1050 1-216-022-00 RES-CHIP 75 5% 1/10W
R1051 1-216-022-00 RES-CHIP 75 5% 1/10W
R1052 1-216-022-00 RES-CHIP 75 5% 1/10W
R1059 1-216-097-11 RES-CHIP 100K 5% 1/10W
R1060 1-216-097-11 RES-CHIP 100K 5% 1/10W
************************************************************
1-688-727-11 VOL BOARD
**********
< CONNECTOR >
* CN1004 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< ROTARY ENCODER >
RV1007 1-477-382-11 ENCODER, ROTARY MASTER VOLUME)
************************************************************
MISCELLANEOUS
**************
60 1-500-249-21 BEAD, FERRITE (CASE) (EXCEPT US, CND)
70 1-827-364-11 WIRE (FLAT TYPE) (23 CORE)
72 1-773-045-11 WIRE (FLAT TYPE) (17 CORE)
154 1-469-969-11 CLAMP, FERRITE (US, CND)
155 1-773-036-11 WIRE (FLAT TYPE) (17 CORE)
156 1-769-878-11 WIRE (FLAT TYPE) (7 CORE) (US, CND)
157 1-769-943-11 WIRE (FLAT TYPE) (11 CORE) (EXCEPT AEP)
157 1-773-007-11 WIRE (FLAT TYPE) (15 CORE) (AEP)
160 1-400-061-11 CORE, FERRITE (CLAMP FILTER) (US, CND)
204 1-500-472-11 CORE, FERRITE
* 206 1-500-169-11 CORE (FPC)
207 1-773-390-11 WIRE (FLAT TYPE) (35 CORE)
