STR-DA5000ES
Pin No. Pin Name I/O Description
114, 115 SDI3, SDI4
I
Audio serial data input terminal Not used
116 SYNC
I
Sync/non-sync setting terminal “L”: sync, “H”: non-sync Fixed at “H” in this set
117 to 119
VSS
—
Ground terminal
120 VDDI
—
Power supply terminal (+2.5V)
