Installation and set-up manual 208668 47
CRANEX Novus e 4. Checking the alignment and fi nishing the installation
Taking a QA exposure:
1. PC: Prepare the unit for an exposure.
2. Attach the Ball and Pin Phantom to the chin
support.
3. Attach the Digital Test Tool (Prüfkörper test
tool) to the Ball and Pin Phantom.
4. Attach the additional fi lter (Cu fi lter) to the
center of the tube head cover, so that it’s over
the fi ltration label. The fi lter has suction cups.
5. Touch the service key on the main control
panel of the unit to open the confi guration
window.
6. Select QA.
Additional Filter
