7 Accessories and Options
Spectra Geospatial 360 Degree Prism
This is a 360° prism comprising 7x25 mm prisms, h:135 mm, prism constant 2 mm. While using this prism
adapter the height can be directly determined at the Spectra Geospatial standard rod.
NOTE – The FOCUS 35 total station is a passive tracking device that allows users to measure and
track a variety of prisms. Necessary prism constants and quality checks are recommended to
maintain high-accuracy measurement results.
The 360 Degree prism including height adapter:
Robotic Components
Robotic rover - for robotic operation there are two ways of external 2.4 GHz radio setup:
l Radio implemented in external CU like the Ranger 7 or Ranger 3 data collector (radio option)
l Separate external radio connected to the data collector via Bluetooth wireless technology
FOCUS 35 Total Station User Guide | 103
