3 Getting Started
Instrument Description
This section describes the instrument controls. Take some time to familiarize yourself with the names
and the locations of the controls.
The following image shows the Operator’s view of the FOCUS 35 Total Station.
Item Description
c
Coarse sight
d
Focusing servo knob
e
Vertical motion servo knob
f
Horizontal motion servo knob
g
On/Off and Trigger key
h
Stylus for touch screen
FOCUS 35 Total Station User Guide | 27
