3 Getting Started
The following image shows the Connector Rubber Cap Placement.
NOTE – Please place the rubber cap in one of the shown directions. Another orientation will limit
the function to insert instrument into tribrach or to turn the instrument.
Optical Plummet
The instrument is equipped with an optical plummet, which has 2x magnification and a focusing range of
0.5 m (1.6 ft) to infinity. The instrument can be positioned to an accuracy of 0.5 mm (0.02 in) at 1.5 m (49
ft) over a ground mark.
FOCUS 35 Total Station User Guide | 29
