3 Getting Started
Control Unit Face2
The Face2 control unit is a graphical display with a built-in backlight and four control buttons.
Function Description
U
Change Face
N
Scroll Up
O
Scroll Down
P
Enter
When a secondary function is available for the keys (N,O or P), an icon appears at the bottom of
the display. To access the secondary function, press the appropriate key.
A long press with the key U starts the Control Unit Face2 Backlight. Without any actions Backlight
turns off after 30 seconds.
NOTE – When the field software is running, the trigger key performs the same function as the
Measurement1 key (M) on the Face1 side and the Enter key (P) at the Face2 side.
FOCUS 35 Total Station User Guide | 34
