6 Instrument Technology
LockNGo Tracking Technology
The FOCUS 35 Total Station is equipped with an image-based tracking system, which is used for robotic
or conventional measurements to lock onto and track a prism.
LockNGo tracking technology controls the instrument StepDrive motor systems and aims the instrument
correctly towards the target.
TIP – To assure maximum performance from the LockNGo tracking technology keep the lens
clean and dry.
The FOCUS 35 Total Station LockNGo tracking function:
The FOCUS 35 Total Station can lock onto and track a prism.
Power Management
The power management in the FOCUS 35 Total Station instrument can set the instrument to one of three
different modes.
l Off Mode
l On Mode - all instrument functions
l Suspend Mode - to save power and replace empty battery
FOCUS 35 Total Station User Guide | 97
