Chapter 9: Ethernet Cards
SmartCards and Modules
94 SmartBits System Reference
SmartCards and Modules
There are two SmartCard/module categories available to use with your SmartBits chassis.
The SmartCards/modules that you will use is based on the requirements of the chassis you
are using. They are defined as follows:
• SmartCards (SMB-200 and SMB-2000).
• Modules (SMB-600 and SMB-6000B.
LEDs on Ethernet SmartCards/modules
Each SmartBits card has a set of LEDs that are similar in functionality but the features
may vary according to the card you are using. Table 9-9 describes the LED functions and
descriptions for all the Ethernet cards.
Table 9-9. LED Functions for Ethernet SmartCards/modules
LED Color/Status Description
TX/INIT Green
Red
Off
Transmitting. LED flashes briefly for each frame
transmitted. If continuous transmission, light appears as a
steady on condition.
Card not initialized. This light is red briefly until the
card boots up.
When chassis and card are not connected, or after card is
initialized.
TRIG CLS Green
Red
Yel low
Trigger Event indication. Flashes briefly for each trigger
detection.
Collision Event. Flashes briefly for each collision event
detected.
Both Collision & Trigger Event occur at same time. In this
case, the flash appears as yellow.
RX ERR Green
Red
Off
Flashes Green once for each frame detected on the network.
Flashes Red once for each bad CRC detected in receive
frames.
Not receiving.
LINK/
DPLX
Green
Yel low
Red
Off
Full duplex with valid link.
Half duplex with valid link (SX-7410).
No link detected.
Half duplex, with valid link (ST-6410).
