Appendix E: SMB-600/6000B Cables and Connectors
Fiber Optic Cable Signals
SmartBits System Reference 227
Fiber Optic Cable Signals
Multi-mode SC Duplex to SC Duplex
LAN-3200A
LAN-3201A
LAN-3201B
Multi-Mode fiber cable: 62.5/125, (50/125 + 100/140) microns (um)
(OCP dtr-1250-SM-L2 850nm)
Min. Avg. Max.
Transmit -11 -7 -3
Receive -3 -- -17
Sensitivity
POS-3500B
POS-3502A
Multi-mode fiber: 62.5/125 microns (um), 0.275 NA graded-index
multimode fiber
Transmitter Performance Min. Typical. Max.
Optical Outputt Power, dBm- -20.00 -18.00 -14.00
Receive Performance
Receiver Sensitivity, P
min
-26.00 -28.00
Max. Input Optical Power, Pmax -14.00 -12.00
