Chapter 9: Ethernet Cards
LAN Series Modules
98 SmartBits System Reference
LAN Series Modules
LAN-3100A and LAN-3200A Series Modules
• LAN-3100A 8-port 10/100 Mbps full/half duplex module
• LAN-3150A 8-port 10/100 Mbps RMII/SMII full/half duplex
• LAN-3200A 2-port 1000 Mbps full duplex (multi-mode) module
• LAN-3200As 2-port 1000 Mbps full duplex (single mode) module
Card Type: 10/100/1000 Mbps Ethernet modules.
Where Used: SMB-600 and SMB-6000B.
Applications
Supported:
SmartWindow, SmartLib, SmartApplications, and AST II.
Devices Tested: Layer 2 and Layer 3 switches and routers; gigabit Ethernet backbones.
Test Objective: A packet-based traffic generator to test performance, conformance, and interoperability of
devices based on industry standard RFCs testing.
Interoperability: Upstream traffic and throughput testing can be performed by using a LAN-3200A module
in combination with the LAN-3100A module.
