Appendix E: SMB-600/6000B Cables and Connectors
Ethernet Cables
222 SmartBits System Reference
Ethernet Cables
Each interface requires a different pin out depending on the type of interface and if the
connection is a DCE-to-DTE or DCE-to-DCE.
Unless otherwise specified, the Ethernet cables specified below use 4 pair category 5
unshielded twisted pair (UTP) cables with a patch length of one meter used between the
RJ-45 connectors.
Straight-through Cable for 10/100/1000 Base
_____________________________________________________________
Crossover Cable for 10/100/1000 Base
Pin Color
1
2
3
4
5
6
7
8
BLUE
BLUE-WHITE
ORANGE
GREEN
GREEN-WHITE
ORANGE-WHITE
BROWN
BROWN-WHITE
Pin
1
2
3
4
5
6
7
8
Color
BLUE
BLUE-WHITE
ORANGE
GREEN
GREEN-WHITE
ORANGE-WHITE
BROWN
BROWN-WHITE
Pin Color
1
2
3
4
5
6
7
8
BLUE
BLUE-WHITE
ORANGE
GREEN
GREEN-WHITE
ORANGE-WHITE
BROWN
BROWN-WHITE
Pin
1
2
3
4
5
6
7
8
Color
ORANGE
ORANGE-WHITE
BLUE
BROWN
BROWN-WHITE
BLUE-WHITE
GREEN
GREEN-WHITE
