Chapter 8: Chassis Specifications
SMB-200/2000 Specifications
SmartBits System Reference 77
Differences between the SMB-200 and SMB-2000
• SMB-200 does not have the DB-37 connectors for the SmartBits stack configuration,
therefore does not support:
– Multiple users.
– SMB-10 extension hub.
• SMB-200 has a 4-slot chassis vs. SMB-2000 which has a 20-slot chassis.
• LEDs:
– SMB-200 has front panel Fan, Link, and Power LEDs, and a reset switch.
– SMB-2000 has only Power and Link LEDs, and no reset switch.
Note: Though the SMB-200 cannot be stacked, it is able to be connected with multiple
chassis via the expansion ports.
SMB-10
The SMB-10 is a 20-slot chassis which connects to and expands the capacity of a SMB-
2000. This chassis is totally dependent on the controller of the connecting SMB-2000, and
is referred to as a “slave.”
Connectors
• RS-232 for workstation connection.
• RJ-45 10Base-T connector for Ethernet connection.
• RJ-45 Expansion In/Out connectors for multiple chassis
connection.
• DB-37 and Hub connectors for stacked multiple chassis.
• Connectors to attach to an optional GPS receiver.
Operating Temperature
Operating Humidity
59-104
°F(15-40°C).
20 to 80% relative humidity, non-condensing.
GPS option Available.
Stacking Requirements Local stacks must be located within 3 feet (1 meter) of each
other.
Cards Supported All SmartCards (Ethernet, Fast Ethernet, Gigabit Ethernet,
ATM, WAN, and Token Ring).
Applications Supported All applications (core and optional).
Table 8-1 SMB-200/2000 Specifications
Category Description
