Appendix E: SMB-600/6000B Cables and Connectors
Fiber Optic Cable Signals
228 SmartBits System Reference
Single-mode SC Duplex to SC Duplex
Single Mode fiber: 8.3/125, (8->10//125) microns (um)
LAN-3200As
(HP HFCT 53D5 1300nm)
Min. Avg. Max.
Transmit = -9.5 -5 -3
Receive = -3 --- -20
Sensitivity
POS-3500Bs
POS-3502As
Transmitter Performance Min. Typical. Max.
Transmit Avg. Optical Power, Le -15.00 -11.00 -8.00 dBm
Center Wavelength
λ
c
, IR 1274 1310 1356
for
∆λ
rms
≤ 2.5 nm
1293 1310 1334
for
∆λ
rms
≤ 4.0 nm
Receiver Performance: Min. Typical. Max.
Receiver Sensitivity, P
min
-30.00 -32.00 – dBm
Max. Input Optical Power, Pmax -7.00 0 – dBm
Wavelength of operation
λ 1100 – 1600 nm
POS-3505As
Transmitter Performance Min. Typical. Max.
Transmit Avg. Optical Power, L1 -10.00 -11.00 -8.00 dBm
Center Wavelength
λ
c
, SR 1266 1310 1360
for
∆λ
rms
≤ 4.0 nm
1293 1310 1334
for
∆λ
rms
≤ 4.0 nm
Receiver Performance: Min. Typical. Max.
Receiver Sensitivity, P
min
-19.00 -22.00 – dBm
Max. Input Optical Power, Pmax -3.00 -1.0 – dBm
Wavelength of operation
λ 1100 – 1600 nm
