Chapter 14: Fibre Channel Cards
Fibre Channel LEDs
SmartBits System Reference 193
Fibre Channel LEDs
Table 14-1 describes the LED functions and descriptions for all the Fibre Channel
modules.
Table 14-1. LED Functions for Fibre Channel Modules
LED Color/Status Description
TX/INIT Green
Red
Off
Transmitting frame.
Card not initialized.
Ready.
RX CRCERR Green
Red
Off
Receiving frame.
Receiving CRC errors.
Not receiving.
TRIG/OSERR Green
Red
Yel low
Receiving trigger.
Receiving encoding errors.
No OS error or trigger.
LINK/Speed Green
Red
Off
Link up @ 2 Gbps.
No GBIC link – loss of signal.
Link up @ 1 Gbps.
