Chapter 11: ATM Cards
ATM LANE Parameters
158 SmartBits System Reference
• UME State.
– Inactive (0) – This is the idle state.
– Down (1) – The physical interface for the card does not have a link.
– Cold Start (2) – The Address Registration procedure is initiated.
– Running (3) – The ATM card has successfully registered an ATM address with the
device under test.
• Cold Starts. A timer that sets the total amount of time between registration requests.
(Default = 5 secs.)
• Good Packets. Number of good packets monitored on the ILMI channel.
• Bad Packets. Number of bad packets monitored on the ILMI channel.
• Sent Packets. Total amount of packets sent by the card.
• ATM Add re ss. Complete 20-byte ATM address composed of 13-byte ATM network
prefix, 6-byte ESI, and 1-byte Selector.
ATM LANE Parameters
Applications
Supported:
SmartWindow, SmartLib.
Card Types: All ATM Cards.
In SmartWindow, the LANE parameters are editable in the LANE tab in the ATM Protocol
Setup window.
Note: To send packets between Ethernet and ATM SmartCards using LANE, you must:
• Send source packets from the Ethernet card so that the device under test can
learn the SmartCard MAC address. Failure to do this will cause an address
resolution failure when attempting to connect a stream from the ATM card to
the Ethernet card.
• To add or edit an ELAN service, click the Add ELAN or Edit ELAN button.
When you click either button, the ELAN Setup window appears.
Parameter definitions for ATM LANE are as follows:
• ELAN Setup Window. Use the ELAN Setup window to specify parameters for the
specific ELAN you want to join.
• ELAN Name. The name of an ELAN that you want to join. The name must exactly
match (case sensitive) one of the ELAN names specified on the device under test.
• MAC Address. The 6-byte MAC address of the LAN Emulation Client on the ATM
SmartCard.
