Chapter 8: Chassis Specifications
SMB-6000/6000B Specifications
78 SmartBits System Reference
SMB-6000/6000B Specifications
Specifications for the SMB-600 and SMB-6000B are the same except as noted in
Table 8-2 below.
Table 8-2 SMB-600/6000B Specifications
Category Description
SMB-600 Dimensions Width: 12 in. (30.5 cm.)
Height: 3.5 in. (8.9 cm.)
Depth: 12.5 in. (31.8 cm.)
Weight: 5.25 lbs. (2.4 kg.) fully loaded
Shipping weight, approximately 8.5 lbs. (3.8 kg.)
SMB-6000B Dimensions Width: 19 in. (48 cm.)
Height: 8.5 in. (22 cm.)
Depth: 16.5 in. (42 cm.)
Weight: 45 lbs. (20.4 kg.) fully loaded
Shipping weight, approximately 48 lbs. (21.8 kg.)
Layout Requirements
• Must have unimpeded airflow into the fans at the side of
the chassis.
• Must be positioned to meet EMI guidelines (see
Appendix C, “Certifications and EMI Compliance,”).
Local connections to multiple chassis must be within 1
meter of each other.
Input power 100-240 VAC. Nominal 115 or 230 VAC, 50-60 Hz.
Controllable over the Internet or from a PC with Windows 98
or Windows NT.
Number of slots
• SMB-600 – 2
• SMB-6000B – 12
Max number of ports
• SMB-600 – 16
• SMB-6000B – 96
Front Panel LEDs
Back Panel LEDs
Power, Fan, Link, and Status.
Activity/Collision, Link/Error, Full/Half Duplex, and 10/100
Ethernet.
