Chapter 9: Ethernet Cards
GX Series SmartCards
SmartBits System Reference 97
Additional
Information:
Additional features can be found in the following tables:
• Table 9-4, “10/100 Mbps Ethernet Cards – Feature Set for SmartMetrics Cards,” on
page 87.
• Table 9-6, “Advanced Gigabit Features,” on page 91.
• Table 9-7, “SMB-200/2000 Gigabit Ethernet Cards — Feature Set Summar,” on
page 92.
Installation Cooling Requirements
If you install the maximum of eight GX-1420B or GX-1421A SmartCards (into 16 card
slots) in an SMB-2000 chassis, be sure to cover the remaining four card slots with blank
panels to maintain proper air flow throughout the chassis. (This is not an issue with the
SMB-200.)
When using less than eight SmartCards in a chassis, you can populate the remaining card
slots with other card types. For every one GX-1420B or GX-1421A card less than the
recommended maximum (eight), you can substitute either:
• One GX-1405B or AT-9xxx SmartCard, or
• Two SX-/ML-xxxx, WN-xxxx, or TR-8405 SmartCards.
Warning: Failure to follow these rules may result in blown fuses within the SMB-2000
chassis. To replace a blown fuse, refer to Chapter 4, “Maintenance and Upgrade
Procedures.”
