Chapter 9: Ethernet Cards
Minimum/Maximum Frame Lengths for Each Card
SmartBits System Reference 85
LAN-3200As 1000 Mbps Full Duplex Fiber
Single Mode
86 2048 24 2K
LAN-3201A 1000 Mbps Multi-Mode 86 2048 32 64K
LAN-3201As 1000 Mbps Single Mode 86 2048 32 64K
LAN-3201B 1000 Mbps GBIC 32 2048 32 64K
LAN-3300A 10/100/1000 Mbps GBIC
LAN-3301A 10/100/1000 Mbps Copper 64 16,384 40 16,384
LAN-3310A 1000 Mbps Single/Multi Mode
GBIC
LAN-3311A 10/100/1000 Mbps Single/Multi
Mode Fiber
64 16,384 40 16,384
LAN-3710A
10G Base (LR/ER) Ethernet
Table 9-2. Min/Max Frame Lengths in Bytes for Ethernet Cards
Card/Module Description
Minimum
Generated
Frame Size
Maximum
Generated
Frame Size
Minimum
Capture
Frame Size
Maximum
Capture
Frame Size
