Chapter 9: Ethernet Cards
Feature Summary of 10/100 Mbps Cards
88 SmartBits System Reference
Comparison of ML-7710 vs LAN-3101A
The LAN-3101A module is a high-port density version of the ML-7710.
The single-port ML-7710 is used with the SMB-200 and SMB-2000. The 6-port LAN-
3101A module is used with the SMB-600 and SMB-6000B.
SmartLib Differences
In SmartLib Version 3.09 and higher, the following commands are used specifically for
the LAN-3101A and ML-7710:
• FST_CAPTURE_INFO (applies to both the ML-7710 and the LAN-3101A).
(None of the other "FST_CAPTURE_n" commands can be used with either the ML-
7710 or the LAN-3101A.)
• The following command is used to show data integrity errors:
ETH_EXTENDED_COUNTER_INFO and a parameter u64RxDataIntegrityErrors
(applies to LAN-3101A).
