VENTILATION, HEATING, AIR CONDITIONING AND AIR PURIFICATION SYSTEM
9-11
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
The fan speed can be
adjusted in 4 different stages.
Hot
Cool
Temperature Control Switch
Adjust the temperature of flowing air by turning the dial.
Red direction: Hot
Blue direction: Cool
Fan Control Switch
Turn the switch clockwise or counterclockwise to increase
or decrease the fan speed.
When the switch is turned to “0”, the fan stops.
If the air conditioner switch is turned off, the air conditioner does
not work even when the fan switch is operated. However, the air
flows due to fan operation.
