COOLANT TEMPERATURE GAUGE
The temperature gauge indicates the temperature of the en-
gine coolant.
FUEL GAUGE
This gauge indicates the level of fuel remaining in the fuel
tank. Fill up the fuel tank before the needle reaches
“E”.
The engine can overheat.
• If the pointer reaches the red zone, stop the vehicle.
• Allow engine to cool.
If the engine is overheated, continued operation of the vehicle
may seriously damage the engine.
CAUTION
