LAMP
14-8
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
REAR COMBINATION LAMP
1. Remove the ignition key from the
key cylinder.
2. Open the tailgate.
3. Disconnect the two mounting
bolts from the rear combination
lamp.
4. Remove the rear combination
lamp from the body.
5. Turn the bulb housing to remove it.
6. Remove the bulb while pushing and
turning it.
7. Replace it with a new one.
8. Install in the reverse order of removal.
Tail lamp /
Stop lamp
Turn signal
lamp
Rear combination lamp
